Features
BLENDS SEAMLESSLY INTO ANY KITCHEN.
The black surface and stainless steel trim align perfectly with every kitchen style.
4 HIGH-LIGHT RADIANT ELEMENTS
Provides quick, reliable, and evenly distributed heat for more consistent cooking.
CERAMIC GLASS SURFACE
Ensures improved safety and easy cleaning.
TOUCH & SLIDE CONTROLS
Adjust and control the power levels with a simple touch and slide design.
DIGITAL TIMER SETTING
The digital timer setting of up to 99 minutes helps coordinate meal preparation and cooking.
9 POWER LEVELS
Allows you to adjust the heat output of each element.
RESIDUAL HEAT INDICATOR
Cooktop indicates when elements are still hot.
AUTOMATIC SWITCH-OFF
The cooktop automatically turns off when overheating.
Specifications
General
Color
Black
Manufacturer Color
Stainless Steel / Black Glass Finish
Fuel Type
Electric
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Total Surface Element Wattage: 6000 W
• Zone / Watts - Front Right: 1200 W
• Zone / Watts - Front Left: 1800 W
• Zone / Watts - Rear Right: 1800 W
• Zone / Watts - Rear Left: 1200 W
• Zone / Watts - Front Right: 1200 W
• Zone / Watts - Front Left: 1800 W
• Zone / Watts - Rear Right: 1800 W
• Zone / Watts - Rear Left: 1200 W
Burner/Element Size
• Diameter of Cooking Zones - Front Right: 6" (152mm)
• Diameter of Cooking Zones - Front Left: 8" (203mm)
• Diameter of Cooking Zones - Rear Right: 8" (203mm)
• Diameter of Cooking Zones - Rear Left: 6" (152mm)
• Diameter of Cooking Zones - Front Left: 8" (203mm)
• Diameter of Cooking Zones - Rear Right: 8" (203mm)
• Diameter of Cooking Zones - Rear Left: 6" (152mm)
Elements
Smoothtop
Surface Features
Ceramic Glass Surface
Features
Control Lock
Yes
Digital Display
Yes
Additional Information
• Frame Colour: Metal Aluminum Frame (Four Sides)
• Beveled Edge: Beveled Edges (Four Sides)
• Cooktop Control Type: Touch & Slide Controls
• Control Location: Front - Center
• Number of Zones: 4 Cooking Zones
• Lighted Icons: Red - LED Light
• Bridge Cooking Element: N/A
• Power Stage Setting: 0-9 Power Levels
• Digital Timer Setting: 00 - 99 minutes
• Residual Heat Indicator
• Automatic Safety Shut Off
• Pause Function
• Beveled Edge: Beveled Edges (Four Sides)
• Cooktop Control Type: Touch & Slide Controls
• Control Location: Front - Center
• Number of Zones: 4 Cooking Zones
• Lighted Icons: Red - LED Light
• Bridge Cooking Element: N/A
• Power Stage Setting: 0-9 Power Levels
• Digital Timer Setting: 00 - 99 minutes
• Residual Heat Indicator
• Automatic Safety Shut Off
• Pause Function
Electrical Information
Information
• Watts: 6000 W
• Electrical Supply: 208 V / 30 Amp, 240 V / 40 Amp
• Frequency: 60 Hz
• Electrical Cable – Hard-wired: 51" (1.3 m)
• Electrical Supply: 208 V / 30 Amp, 240 V / 40 Amp
• Frequency: 60 Hz
• Electrical Cable – Hard-wired: 51" (1.3 m)
Dimensions
Class Width
36"
Width
23.25 inch(es) / 59.06 cm
Height
20.5 inch(es) / 52.07 cm
Depth
3.13 inch(es) / 7.95 cm
Additional Dimensions
Cut-Out Dimensions (W / D): 22 1/16" x 19 5/16" (560 mm x 490 mm)
Warranty
Warranty
2-year parts and labor
