Features
BRIDGE ZONE FUNCTION
The Bridge function combines two cooking zones together to fit any large or long pan. Sharing the same temperature and time setting, the linked zones are ideal when you’re cooking for dinner parties or bigger celebrations.
TOUCH & SLIDE DESIGN CONTROLS
The touch & slide design controls user interface allows for precise temperature control in an instant without having to toggle through the plus and minus buttons. Heat levels can be adjusted quickly, easily, and accurately.
QUICKER HEAT FOR EXTRA SPEED WITH POWERBOOST
A blast of fast. No more waiting around for pots to boil. The PowerBoost function gives you an instant burst of heat. PowerBoost is perfect for tasks that require you to boil a large pot of water quickly.
PAUSE FUNCTION
The pause function is useful if your cooking is interrupted. With the touch of a button all cooking zones will pause the cooking process, whilst another restarts it again with the same settings.
Specifications
General
Color
Black
Manufacturer Color
Black Ceramic Glass / Beveled Edges / Metal Frame
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Zone / Power Boost Watts - Front Right: 1200 W / 1500 W Power Boost
• Zone / Power Boost Watts - Front Left: 2000 W / 2600 W Power Boost
• Zone / Power Boost Watts - Rear Right: 1800 W / 2300 W Power Boost
• Zone / Power Boost Watts - Rear Left: 2000 W / 2600 W Power Boost
• Bridge Zone / Power Boost Watts - Left: 3600 W
• Zone / Power Boost Watts - Front Left: 2000 W / 2600 W Power Boost
• Zone / Power Boost Watts - Rear Right: 1800 W / 2300 W Power Boost
• Zone / Power Boost Watts - Rear Left: 2000 W / 2600 W Power Boost
• Bridge Zone / Power Boost Watts - Left: 3600 W
Burner/Element Size
• Diameter of Cooking Zones - Front Right: 6" (152mm)
• Diameter of Cooking Zones - Front Left: 81/2" x 81/2" (216mm x 216mm)
• Diameter of Cooking Zones - Rear Right: 7" (177mm)
• Diameter of Cooking Zones - Rear Left: 81/2" x 81/2" (216mm x 216mm)
• Diameter of Bridge Zone - Left: 81/2" x 17" (216mm x 431mm)
• Diameter of Cooking Zones - Front Left: 81/2" x 81/2" (216mm x 216mm)
• Diameter of Cooking Zones - Rear Right: 7" (177mm)
• Diameter of Cooking Zones - Rear Left: 81/2" x 81/2" (216mm x 216mm)
• Diameter of Bridge Zone - Left: 81/2" x 17" (216mm x 431mm)
Elements
Smoothtop
Features
Control Lock
Yes
Digital Display
Yes
Additional Information
• Cooktop Control Type Touch & Slide Design Controls
• Control Location Front - Right
• Number of Zones: 4 Cooking Zones
• Lighted Icons: Red - LED Light
• Bridge Zone Cooking Element: Left Side
• Power Stage Setting: 0-9 Power Levels
• Power Boost Control
• Digital Timer Control: 00-99 minutes
• Pause Function
• Keep Warm Control
• Residual Heat Indicator
• Automatic Safety Switch Off
• Control Location Front - Right
• Number of Zones: 4 Cooking Zones
• Lighted Icons: Red - LED Light
• Bridge Zone Cooking Element: Left Side
• Power Stage Setting: 0-9 Power Levels
• Power Boost Control
• Digital Timer Control: 00-99 minutes
• Pause Function
• Keep Warm Control
• Residual Heat Indicator
• Automatic Safety Switch Off
Electrical Information
Information
• Total Connected Load: 7200 W
• Amperage (AMP): 40 AMP
• Power Range / Rated Voltage: AC 208V ~ 60Hz ~ 6.2kW or AC 240V ~ 60Hz ~ 7.2kW
• Power Cord Length: 51" (1300mm)
• Amperage (AMP): 40 AMP
• Power Range / Rated Voltage: AC 208V ~ 60Hz ~ 6.2kW or AC 240V ~ 60Hz ~ 7.2kW
• Power Cord Length: 51" (1300mm)
Dimensions
Class Width
24"
Width
23.25 inch(es) / 59.06 cm
Height
3.56 inch(es) / 9.04 cm
Depth
20.5 inch(es) / 52.07 cm
Additional Dimensions
Cut-Out Dimensions (W / H / D): 22 1/16" x min. 5 1/16" x 19 5/16" (560mm x min. 129mm x 490mm)
Warranty
Warranty
Parts & Labor: 2 Years
