Features
COOL FLOW SYSTEM
Unique Cool Flow System that generates a flow of cold air thanks to inner fans that are engineered to keep cool to the touch knobs, handle, and exterior surfaces.
BLACK ENAMEL SURFACE
Exclusive one-piece, tooled black enamel cooking surface, modern design, resilient to scratches, and contains spills for easy cleaning.
CAST IRON SUPPORT GRATES
Heavy-duty cast-iron grates, so pots and pans can be moved from one burner to another easily and without risk of tipping over.
LARGE PANORAMIC WINDOW
Triple-pane glass, a large panoramic window provides a clear view of what’s cooking, cool touch surface.
SIX BURNERS
A total of 6 sealed gas burners offer a combined output of 63,600 BTUs. The special simmer burner offers an ideal 750 BTUs of output for a precise simmering temperature.
CONVECTION OVEN - RDF36
The oven features 4 convection fans to evenly circulate heat throughout the oven, producing tastier results than traditional radiant heating methods.
Specifications
General
Series Name
Regent Series
Fuel Type
Dual Fuel - Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel with Black Enamel Cooktop
Cooktop
Burners/Elements
6
Burners/Elements Output
• Simmer Burner
• Power Burner
• Burner 1 Output: 18,000 BTU (Power Burner with Simmer)
• Burner 2 Output: 18,000 BTU (Power Burner)
• Burner 3 Output: 11,000 BTU (Large Burner)
• Burner 4 Output: 6,500 BTU (Medium Burner)
• Burner 5 Output: 6,500 BTU (Medium Burner)
• Burner 6 Output: 3,600 BTU (Auxiliary)
• Power Burner
• Burner 1 Output: 18,000 BTU (Power Burner with Simmer)
• Burner 2 Output: 18,000 BTU (Power Burner)
• Burner 3 Output: 11,000 BTU (Large Burner)
• Burner 4 Output: 6,500 BTU (Medium Burner)
• Burner 5 Output: 6,500 BTU (Medium Burner)
• Burner 6 Output: 3,600 BTU (Auxiliary)
Burners
Sealed
Oven
Capacity (cu. ft.)
6.7
Number of Ovens
Single
Features
Convection
Yes
Oven Light
Yes
Self-Cleaning
No
Additional Information
• Fuel Type: Dual fuel / Natural gas – Propane
• Stainless Steel Handle
• Cooktop / Oven Control Type: Rotary Knobs
• Control Panel Indicators: Thermostat Pilot Lamp, Oven Switch Pilot Lamp
• Viewing Window
• Door Type: Fully Flush
• Removable Drip Tray: Standard
• Wok Ring: Standard
• Cooktop surface: Black Enamel
• Continuous support grates
• LPG Conversion kit
• Oven Type: Convection oven / 2 Convection Elements
• Fans: 4 Convection Fans
• Racks: 2 Heavy Duty Racks
• Rack Positions: 6
• Glide Rack(s): Yes
• Temperature Display: °C & °F
• Broiler Element Location: Top
• Broiler Pan Included: Yes, Plus Grill Insert
• Interior Oven Light: Side Wall
• Removable Door
• Cooking Functions: 7 Functions, incl. True Fan Convection, Conventional, Bake + Fan and Broil + Fan
• Stainless Steel Handle
• Cooktop / Oven Control Type: Rotary Knobs
• Control Panel Indicators: Thermostat Pilot Lamp, Oven Switch Pilot Lamp
• Viewing Window
• Door Type: Fully Flush
• Removable Drip Tray: Standard
• Wok Ring: Standard
• Cooktop surface: Black Enamel
• Continuous support grates
• LPG Conversion kit
• Oven Type: Convection oven / 2 Convection Elements
• Fans: 4 Convection Fans
• Racks: 2 Heavy Duty Racks
• Rack Positions: 6
• Glide Rack(s): Yes
• Temperature Display: °C & °F
• Broiler Element Location: Top
• Broiler Pan Included: Yes, Plus Grill Insert
• Interior Oven Light: Side Wall
• Removable Door
• Cooking Functions: 7 Functions, incl. True Fan Convection, Conventional, Bake + Fan and Broil + Fan
Electrical Information
Information
• Volts (V): 120/240 V
• Frequency (Hz): 60 Hz
• Maximum Temperature: 260 °C / 500 °F
• Maximum Power: 3540 W
• Supplied with Range Cord and Plug: NEMA configuration 14-50P
• Frequency (Hz): 60 Hz
• Maximum Temperature: 260 °C / 500 °F
• Maximum Power: 3540 W
• Supplied with Range Cord and Plug: NEMA configuration 14-50P
Accessories
Included
Cooktop Accessory: Wok Ring Adaptor, Espresso Trivet
Dimensions
Class Width
36"
Width
35.87 inch(es) / 91.11 cm
Height
35.87 inch(es) / 91.11 cm
Depth (Including Handles)
26.87 inch(es) / 68.25 cm
Additional Dimensions
• Interior Dimensions (W / H / D): 28 3/4" x 20 1/2" x 19 13/16"
• Exterior Width Dimensions: 35 7/8"
• Exterior Width Dimensions: 35 7/8"
Warranty
Warranty
Parts & Labour: 2 Years
