Features
EUCLID - EASE OF OPERATION
Electronic touch controls for 3-speed blower and LED lights.
EUCLID - EASY CLEANING
Dishwasher safe, commercial style baffle filters for effectively removing airborne contaminants. Detergent inlet holes and grease exit holes in baffle filters for superior dishwasher cleaning.
EUCLID - ENERGY EFFICIENT OPERATION
LED light bulbs draw only 6 watts each and energy efficient motors draw only 2.5 amps.
EUCLID - FLEXIBLE INSTALLATION
Mounting bars at top and bottom allow for attaching to stud supports. Open top and back design for centered duct location or offset top duct and/or rear offset discharge.
EUCLID - LIGHTING
Bright LED lighting offers natural looking, 3000K color spectrum. The 36" hood features 2 lights, the 48" hood features 3 lights.
EUCLID - QUIET OPERATION
Large 3-speed blower operates at lower RPM reducing the sound level.
Specifications
General
Series Name
Euclid
Blower Included
Yes
Airflow
1200 CFM
Style
Chimney
Color
Black
Manufacturer Color
Matte Black with Brushed Brass Trim
Installation
Wall Mount
Features
Dishwasher-Proof Filters
Yes
Speeds
3 Speeds
Additional Information
• Trapezoid Hood Style
• Hood Sone Level: Ranges from 5-7
• Bright LED Lighting
• Baffle Filters
• Hood Sone Level: Ranges from 5-7
• Bright LED Lighting
• Baffle Filters
Dimensions
Class Width
48"
Width
48 inch(es) / 121.92 cm
Height
30 inch(es) / 76.2 cm
Depth
24 inch(es) / 60.96 cm
Weight
125.99 lb(s) / 57.15 kg
Warranty
Warranty
2 Years
