Features
AUTOMATIC ICE MAKER
Internal water dispenser with inline filter for hygienically clean drinking water and ice.
DIGITAL LED TOUCH CONTROLS
Digital LED touch interface with user-friendly controls for temperature, speed-freeze and ice making
Specifications
General
Refrigerator Type
Bottom Freezer
Installation Type
Built-In
Door Hinge
Right
Reversible Doors
Yes
Color
Panel Ready
Manufacturer Color
Panel Ready
Capacity
Total
16.0 cu. ft.
Refrigerator
11.5 cu. ft.
Freezer
4.5 cu. ft.
Refrigerator Features
Digital Display
Yes
Frost Free
Yes
Interior Light
Yes
Crisper Drawers
Yes
Gallon Door
Yes
Additional Information
• Internal digital LED touch interface
• Top and sidewall LED lights
• Refrigerator shelves: 1 stationary + 2 height-adjustable
• Refrigerator crispers: 1 + 1 with separate temperature control
• Door storage: 1 gallon sized + 2 height adjustable bins
• Settings: Super cool, Super freeze, Ice maker, Water filter replacement alarm, Water dispenser, Eco mode, Vacation mode, Sabbath mode
• Water connection: 1/4" waterline with shut-off valve
• Water supply pressure: 25-80 PSI (1.7-5.5 BAR)
• Top and sidewall LED lights
• Refrigerator shelves: 1 stationary + 2 height-adjustable
• Refrigerator crispers: 1 + 1 with separate temperature control
• Door storage: 1 gallon sized + 2 height adjustable bins
• Settings: Super cool, Super freeze, Ice maker, Water filter replacement alarm, Water dispenser, Eco mode, Vacation mode, Sabbath mode
• Water connection: 1/4" waterline with shut-off valve
• Water supply pressure: 25-80 PSI (1.7-5.5 BAR)
Freezer Features
Additional Freezer Information
2 drawers
Ice and Water
Ice System
Interior
Filtration
Yes
Dispenser Features
Automatic ice maker 3.9 lbs / 24 hrs
Electrical Information
Information
• 115 V
• 60 Hz
• 2.6 A
• Power connection NEMA 5-15P with 98" power cord
• 551.0 kwh/yr
• 60 Hz
• 2.6 A
• Power connection NEMA 5-15P with 98" power cord
• 551.0 kwh/yr
Certifications and Approvals
Energy Star Certified
Yes
ADA Compliant
Yes
Sabbath Mode
Yes
Additional Information
CEC, ETL
Accessories
Optional
• Z370001 Replacement Water Filter
• PROHK30PI Handle Kit - Professional Series
• MASHK30PI Handle Kit - Master Series
• HERHK30PI Handle Kit - Heritage Series
• CTBMPV Connection Trim for Side-by-Side Installation
• PROHK30PI Handle Kit - Professional Series
• MASHK30PI Handle Kit - Master Series
• HERHK30PI Handle Kit - Heritage Series
• CTBMPV Connection Trim for Side-by-Side Installation
Dimensions
Class Width
29" to 31.9"
Class Height
50" - 55"
Width
29.75 inch(es) / 75.57 cm
Height (With Hinge)
51.06 inch(es) / 129.69 cm
Depth (Without Handles)
24.25 inch(es) / 61.6 cm
Weight
386.01 lb(s) / 175.09 kg
Shipping Dimensions
Width
32.31 inch(es) / 82.07 cm
Height
90.58 inch(es) / 230.08 cm
Depth
26.37 inch(es) / 66.99 cm
Warranty
Warranty
2 Years Parts and Labor
