Specifications
General
Color
Black
Manufacturer Color
Black
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
5
Power Output
• Front Left Element: 2100 W (3000 W)
• Back Left Element: 2100 W (3000 W)
• Center Element: 2300 W (3000 W)
• Front Right Element: 1400 W (1850 W)
• Back Right Element: 2300 W (3000 W)
• Back Left Element: 2100 W (3000 W)
• Center Element: 2300 W (3000 W)
• Front Right Element: 1400 W (1850 W)
• Back Right Element: 2300 W (3000 W)
Burner/Element Size
• Front Left Element: 7 1/2 x 8 1/4
• Back Left Element: 7 1/2 x 8 1/4
• Center Element: Ø 9 13/16
• Front Right Element: Ø 5 11/16
• Back Left Element: 7 1/2 x 8 1/4
• Center Element: Ø 9 13/16
• Front Right Element: Ø 5 11/16
Elements
Smoothtop
Features
Technologies
Flexi-Zone Technology
Control Lock
Yes
Digital Display
Yes
Additional Information
• Concealed Digital Slider with White LED
• Grill function
• Timer
• Pause and Recal
• Residual heat indicator
• Grill function
• Timer
• Pause and Recal
• Residual heat indicator
Electrical Information
Information
• 208 V - 60 HZ / 240 V - 60 HZ
• 11100 W
• 48 Amp
• Power connection: Metal conduit with 71" power cord
• 11100 W
• 48 Amp
• Power connection: Metal conduit with 71" power cord
Certifications and Approvals
Information
UL
Accessories
Optional
GR22ICI: Cast iron griddle for induction
Dimensions
Class Width
36"
Width
35.38 inch(es) / 89.87 cm
Height
2.5 inch(es) / 6.35 cm
Depth
20.5 inch(es) / 52.07 cm
Weight
39.99 lb(s) / 18.14 kg
Additional Dimensions
Cut-out dimensions: 33.13"W x 2.75"H x 18.75"D
Shipping Dimensions
Width
41.14 inch(es) / 104.5 cm
Height
6.3 inch(es) / 16 cm
Depth
26.19 inch(es) / 66.52 cm
Weight
44 lb(s) / 19.96 kg
