Features
ELECTRONIC RE-IGNITION
Electronic re-ignition will automatically re-ignite the burner in case the flame goes out
HEAVY-DUTY METAL KNOBS
Heavy-duty metal knobs for a Premium look and feel.
OPTISIM® BURNER
OptiSim® Burner – simmer delicate sauces and melt chocolate without scorching
RED LED LIGHT
Distinctive red LED light indicates burners are on
Specifications
General
Series Name
800 Series
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Natural Gas
Type
Built-In
Cooktop
Burners/Elements
5
Power Output
• Total BTU (NG / LP): 50,000 / 43,200
• Front Left (NG / LP): 10,000 / 9,100
• Back Left (NG / LP): 5,500 / 5,000
• Center (NG / LP): 19,000 / 15,000
• Back Right (NG / LP): 10,000 / 9,100
• Front Right (NG / LP): 5,500 / 5,000
• Front Left (NG / LP): 10,000 / 9,100
• Back Left (NG / LP): 5,500 / 5,000
• Center (NG / LP): 19,000 / 15,000
• Back Right (NG / LP): 10,000 / 9,100
• Front Right (NG / LP): 5,500 / 5,000
Burners
Sealed
Surface Features
Cast Iron Grates
Features
Technologies
OptiSim® Burner
Additional Information
• Low-Profile Design for an Integrated Appearance
• Seamless, One-piece Stainless Steel Design
• Heavy-Duty Metal Knobs for a Premium Look and Feel
• Distinctive Red LED Light Power on Indicator
• Electronic Automatic Re-Ignition
• Location of Gas Connection: Bottom, Rear, Right
• Seamless, One-piece Stainless Steel Design
• Heavy-Duty Metal Knobs for a Premium Look and Feel
• Distinctive Red LED Light Power on Indicator
• Electronic Automatic Re-Ignition
• Location of Gas Connection: Bottom, Rear, Right
Electrical Information
Information
• 15 A
• 120 V
• 60 Hz
• 360 W
• 120 V
• 60 Hz
• 360 W
Certifications and Approvals
ADA Compliant
Yes
Sabbath Mode
Yes
Accessories
Included
LP Conversion Kit
Dimensions
Class Width
30"
Width
31.02 inch(es) / 78.8 cm
Height
21.26 inch(es) / 54 cm
Depth
3.82 inch(es) / 9.7 cm
Weight
36.99 lb(s) / 16.78 kg
Additional Dimensions
• Required Cutout Size (HxWxD): 3 13/16" x 28 15/16" x 19 1/8"
• Minimum Distance from Counter Front: 1 7/8"
• Minimum Distance from Rear Wall: 3"
• Power Cord Length: 152 Cm
• Minimum Distance from Counter Front: 1 7/8"
• Minimum Distance from Rear Wall: 3"
• Power Cord Length: 152 Cm
Shipping Dimensions
Weight
44.09 lb(s) / 20 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
UPC
UPC#
8.25E+11
