Features
POWER BURNER
Power burner
12” GRIDDLE AND 12” BBQ GRILL
12” Griddle and 12” BBQ Grill
Specifications
General
Series Name
CULINARIAN
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Natural Gas
Type
Rangetop
Cooktop
Burners/Elements
6
Power Output
• Three 25,000 BTU open style burners turn down to a True Simmer
• One 8,000 BTU Small Pan Burner turns down to an extra low simmer
• One 18,000 BTU BBQ Grill Burner
• One 18,000 BTU Stainless Steel Griddle Plate
• One 8,000 BTU Small Pan Burner turns down to an extra low simmer
• One 18,000 BTU BBQ Grill Burner
• One 18,000 BTU Stainless Steel Griddle Plate
Burner/Element Size
• 12 inch wide BBQ Grill Burner with Cast Iron Porcelain Coated Grates Hybrid Radiants and Stainless Steel Cover
• 12 inch wide Stainless Steel Griddle Plate with Thermostatic Control and Stainless Steel Cover
• 12 inch wide Stainless Steel Griddle Plate with Thermostatic Control and Stainless Steel Cover
Burners
Open
Other
Griddle,Grill
Surface Features
• Stay-Cool™ die cast, chrome plated metal knobs
• Professional stye heavy duty cast iron grates with easy to clean matte porcelain finish
• Professional stye heavy duty cast iron grates with easy to clean matte porcelain finish
Features
Clock
No
Control Lock
No
Digital Display
No
Downdraft Ventilation
No
Additional Information
• Full extension Drip Trays on EZ-Glides
• Flush Island trim
• All burner have auto ignition and re-ignition
• Stay-Cool™ – Die cast, chrome plated metal knobs with Black Trims (cabernet red optional)
• Flush Island trim
• All burner have auto ignition and re-ignition
• Stay-Cool™ – Die cast, chrome plated metal knobs with Black Trims (cabernet red optional)
Electrical Information
Information
120
Certifications and Approvals
Sabbath Mode
No
Dimensions
Class Width
48" or More
Width
47.87 inch(es) / 121.6 cm
Height
8.25 inch(es) / 20.96 cm
Depth
27.13 inch(es) / 68.9 cm
Weight
280.01 lb(s) / 127.01 kg
Additional Dimensions
• Cutout Dimension:Standard Installation: 46-15/16" W x 23-1/8" D. No bottom platform required. 9" min. clearance to drawers
• Shipping Dimensions: 52" W x 20" H x 32" D
• Product Dimensions:47-7/8" W 8-1/4" H 27-1/8" D
• Shipping Dimensions: 52" W x 20" H x 32" D
• Product Dimensions:47-7/8" W 8-1/4" H 27-1/8" D
Shipping Dimensions
Weight
320 lb(s) / 145.15 kg
Warranty
Warranty
• ONE (1) Year full parts and labor covers entire product with the exception of painted or decorative parts listed below*. (Light bulbs covered for 60 days after installation.) Standard shipping only. Expedited shipping will be at customers' expense.
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables.
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables.
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
