Features
FLEX-ROLL™ OVEN RACKS
Oven racks for smooth operation in self-clean ranges.
Additional Features
EZ-GLIDES™
Full extension removable drip trays mounted on ball bearing rails.
HEAVY-DUTY CONTINUOUS GRATES
Heavy-duty continuous grates for easy mobility on the rangetop.
Specifications
General
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
5
Burners/Elements Output
• Three (3) 25,000 BTU open style burners turn down to a True Simmer
• One (1) 8,000 BTU Small Pan Burner turns down to an extra low simmer
• One (1) 12 inch wide 18,000 BTU BBQ Grill Burner with Cast Iron Porcelain Coated Grates Hybrid Radiants and Stainless Steel Cover
• One (1) 8,000 BTU Small Pan Burner turns down to an extra low simmer
• One (1) 12 inch wide 18,000 BTU BBQ Grill Burner with Cast Iron Porcelain Coated Grates Hybrid Radiants and Stainless Steel Cover
Burners
Open
Other
Grill
Oven
Capacity (cu. ft.)
4.6 cu. ft.
Number of Ovens
Single
Programs
• Bake
• Broil
• Convection Bake
• Convection Broil
• Broil
• Convection Bake
• Convection Broil
Features
Technologies
• EZ-Glides™
• Stay-Cool™ die cast
• Moto-Rotis™ motorized
• Stay-Cool™ die cast
• Moto-Rotis™ motorized
Convection
Yes
Oven Light
Yes
Self-Cleaning
Yes
Electrical Information
Information
• 120 V
• 60 Hz
• 9 Amp
• 60 Hz
• 9 Amp
Dimensions
Class Width
36"
Width
35.87 inch(es) / 91.11 cm
Warranty
Warranty
• 1-Year Parts and Labor
• 5-Year Limited Parts Replacement
• 5-Year Limited Parts Replacement
