Features
FLEX-ROLL™ OVEN RACKS
Oven racks for smooth operation in self-clean ranges.
OPEN BURNERS
Each burner produces 25,000 BTUs
of searing heat and also turns down to
a delicate, consistent simmer, offering
precise control. Perfect for the cooking
connoisseur.
Additional Features
STAY-COOL™ KNOBS
Die cast chrome-plated metal knobs with black trims.
Specifications
General
Series Name
CULINARIAN
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
5
Burners/Elements Output
• Three 25,000 BTU open style burners turn down to a True Simmer
• One 8,000 BTU Small Pan Burner turns down to an extra low simmer
• One 24 inch wide BBQ Grill Burner with two 18,000 BTU burners and Cast Iron Porcelain Coated Grates Hybrid
• One 8,000 BTU Small Pan Burner turns down to an extra low simmer
• One 24 inch wide BBQ Grill Burner with two 18,000 BTU burners and Cast Iron Porcelain Coated Grates Hybrid
Burner/Element Size
24" BBQ Grill
Burners
Open
Other
Grill
Oven
Capacity (cu. ft.)
• Large Oven : 4.9
• Small Oven : 2.0
• Total Capacity : 6.9
• Small Oven : 2.0
• Total Capacity : 6.9
Number of Ovens
Double
Features
Convection
Yes
Delay Bake/Start
No
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• BAKE (Both ovens)
• BROIL
• CONVECTION BAKE (Primary and 60" companion ovens)
• CONVECTION BROIL
• SELF-CLEAN (Large oven)
• Extra Large Oven fits Full Size Commercial Cookie Sheets (Large oven)
• Infrared Broiler Under Glass (Large oven)
• Integrated Moto-Rotis Rotisserie system (Large oven)
• 5 rack positions
• Flex-Roll oven racks for smooth operation
• Removable Door with Heavy Duty Hinges
• Front located Gas Shut-Off Valve and Electrical Disconnect
• 30,000 BTU oven burner for uniform baking (Large oven)
• 18,000 BTU Infrared Broil Burner Under Glass with Inconel (Large oven)
• 15,000 BTU oven burner for uniform baking (Small oven)
• Stay-Cool™ die cast, chrome plated metal knobs
• Natural Gas: 7" WC input pressure: 5" WC pressure regulator provided
• Liquid Propane: 11" WC input pressure: 10" WC pressure regulator provided
• BROIL
• CONVECTION BAKE (Primary and 60" companion ovens)
• CONVECTION BROIL
• SELF-CLEAN (Large oven)
• Extra Large Oven fits Full Size Commercial Cookie Sheets (Large oven)
• Infrared Broiler Under Glass (Large oven)
• Integrated Moto-Rotis Rotisserie system (Large oven)
• 5 rack positions
• Flex-Roll oven racks for smooth operation
• Removable Door with Heavy Duty Hinges
• Front located Gas Shut-Off Valve and Electrical Disconnect
• 30,000 BTU oven burner for uniform baking (Large oven)
• 18,000 BTU Infrared Broil Burner Under Glass with Inconel (Large oven)
• 15,000 BTU oven burner for uniform baking (Small oven)
• Stay-Cool™ die cast, chrome plated metal knobs
• Natural Gas: 7" WC input pressure: 5" WC pressure regulator provided
• Liquid Propane: 11" WC input pressure: 10" WC pressure regulator provided
Drawer Features
Indicator Light
No
Electrical Information
Information
120
Dimensions
Class Width
48"
Width
47.87 inch(es) / 121.6 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
28.37 inch(es) / 72.07 cm
Weight
560 lb(s) / 254.01 kg
Additional Dimensions
• Companion Oven Dimensions: 15" W X 15" H X 21" D
• Primary Oven Dimensions: 27" W x 15" H x 21"
• Cutout Dimension: 48-1/8"W X 24"D (std)
• For more information refer to dimension guide
• Primary Oven Dimensions: 27" W x 15" H x 21"
• Cutout Dimension: 48-1/8"W X 24"D (std)
• For more information refer to dimension guide
Shipping Dimensions
Weight
600.01 lb(s) / 272.16 kg
Warranty
Warranty
• ONE (1) Year full parts and labor covers entire product with the exception of painted or decorative parts listed below*. (Light bulbs covered for 60 days after installation.) Standard shipping only. Expedited shipping will be at customers' expense
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
