Features
POWER-FLO™ BURNERS (19,000 BTU - 140 DEG. SIMMER)
Capital exclusive feature: Optional cabernet red knobs Power-Flo™ burners.
19,000 BTU - 140 deg. simmer.
MOTO-ROTIS™ MOTORIZED ROTISSERIE SYSTEM
Outdoor BBQ technology comes indoors. The industry’s first motorized rotisserie system allows you to broil mouth-watering, evenly-cooked meals at up to 550°F. Rotisserie split rod and prongs are made of heavy-duty, stainless steel, are built to last and a snap to clean. Basting pan included.
FLEX-ROLL™ OVEN RACKS
Oven racks for smooth operation in self-clean ranges.
INFRA-Q™ BBQ GRILL
Boasts 18,000 BTU of searing heat output with variable temperature control and even heat.
Additional Features
STAY-COOL™ KNOBS
Die cast chrome-plated metal knobs with black trims.
THERMO-GRIDDLE™
Solid stainless steel thermostatically controlled griddle plate gives you precise control over the griddle area.
Specifications
General
Series Name
PRECISION
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
6
Burners/Elements Output
• Four 19,000 BTU Power-Flo™ Sealed burners turn down to a true simmer
• One 18,000 BTU BBQ Grill
• One 18,000 BTU Thermo-Griddle™
• One 18,000 BTU BBQ Grill
• One 18,000 BTU Thermo-Griddle™
Burner/Element Size
• One 12"BBQ Grill
• One 12" Thermo-Griddle™
• One 12" Thermo-Griddle™
Burners
Sealed
Other
Griddle,Grill
Oven
Capacity (cu. ft.)
• Large Oven : 4.9
• Small Oven : 2.0
• Total Capacity : 6.9
• Small Oven : 2.0
• Total Capacity : 6.9
Number of Ovens
Double
Features
Convection
Yes
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Self-Cleaning Convection oven (Large Oven)
• BAKE (Both Ovens)
• CONVECTION BAKE (Large Oven)
• BROIL CONVECTION BROIL
• 30,000 BTU oven burner for uniform baking (Large Oven)
• 18,000 BTU Infrared Broil Burner Under Glass with Inconel Mesh construction (Large Oven)
• Moto-Rotis integrated Rotisserie System (Large Oven)
• Titanium speck porcelain oven interior (Both Ovens)
• 5 Rack Positions w/ 3 Heavy Duty Racks provided
• Broil pan provided
• 1-1/4" diameter professional-style handle
• Heavy-duty oven door hinges
• Bright 40W oven lights (Both Ovens)
• Manual Clean (Small Oven)
• 15,000 BTU oven burner for uniform baking (Small Oven)
• Stay-Cool™ die cast, chrome plated metal knobs
• All burner have auto ignition and re-ignition
• BAKE (Both Ovens)
• CONVECTION BAKE (Large Oven)
• BROIL CONVECTION BROIL
• 30,000 BTU oven burner for uniform baking (Large Oven)
• 18,000 BTU Infrared Broil Burner Under Glass with Inconel Mesh construction (Large Oven)
• Moto-Rotis integrated Rotisserie System (Large Oven)
• Titanium speck porcelain oven interior (Both Ovens)
• 5 Rack Positions w/ 3 Heavy Duty Racks provided
• Broil pan provided
• 1-1/4" diameter professional-style handle
• Heavy-duty oven door hinges
• Bright 40W oven lights (Both Ovens)
• Manual Clean (Small Oven)
• 15,000 BTU oven burner for uniform baking (Small Oven)
• Stay-Cool™ die cast, chrome plated metal knobs
• All burner have auto ignition and re-ignition
Drawer Features
Indicator Light
No
Electrical Information
Information
120
Certifications and Approvals
Sabbath/Star-K
No
Dimensions
Class Width
48"
Width
47.87 inch(es) / 121.6 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
28.37 inch(es) / 72.07 cm
Weight
560 lb(s) / 254.01 kg
Additional Dimensions
• Cutout Dimension: 48-1/8"W X 24"D (std)
• Primary Oven Dimensions: 27" W x 14" H x 21" D
• Companion Oven Dimensions: 12" W x 14" H x 21" D
• For more information refer to dimension guide
• Primary Oven Dimensions: 27" W x 14" H x 21" D
• Companion Oven Dimensions: 12" W x 14" H x 21" D
• For more information refer to dimension guide
Shipping Dimensions
Weight
600.01 lb(s) / 272.16 kg
Warranty
Warranty
• ONE (1) Year full parts and labor covers entire product with the exception of painted or decorative parts listed below*. (Light bulbs covered for 60 days after installation.) Standard shipping only. Expedited shipping will be at customers' expense
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
