Features
FLEX-ROLL™ OVEN RACKS
Oven racks for smooth operation in self-clean ranges.
Additional Features
STAY-COOL™ KNOBS
Die cast chrome-plated metal knobs with black trims.
EZ-GLIDES™
Full extension removable drip trays mounted on ball bearing rails.
Specifications
General
Series Name
PRECISION
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
7
Burners/Elements Output
• Six 19,000 BTU Power-Flo™ Sealed burners turn down to a true simmer
• 30,000 BTU Built in Power-Wok™
• 30,000 BTU Built in Power-Wok™
Burner/Element Size
24" Power-Wok™
Other
Wok
Oven
Capacity (cu. ft.)
• Large Oven : 4.9
• Small Oven : 3.1
• Total Capacity : 8.0
• Small Oven : 3.1
• Total Capacity : 8.0
Number of Ovens
Double
Features
Control Lock
No
Convection
Yes
Delay Bake/Start
No
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• BAKE (both ovens)
• BROIL
• CONVECTION BAKE (primary and 60" companion ovens)
• CONVECTION BROIL
• SELF-CLEAN (primary ovens)
• Extra Large Oven fits Full Size Commercial Cookie Sheets (primary oven)
• Infrared Broiler Under Glass (primary oven)
• Integrated Moto-Rotis Rotisserie system (primary oves)
• 5 rack positions
• Flex-Roll oven racks for smooth operation
• Removable Door with Heavy Duty Hinges
• Front located Gas Shut-Off Valve and Electrical Disconnect
• 30,000 BTU oven burner for uniform baking (primary oven)
• 18,000 BTU Infrared Broil Burner Under Glass with Inconel (primary oven)
• 22,000 BTU oven burner for uniform baking ( companion oven)
• Stay-Cool™ die cast, chrome plated metal knobs
• Professional style heavy duty cast iron grates with easy to clean matte porcelain finish
• BROIL
• CONVECTION BAKE (primary and 60" companion ovens)
• CONVECTION BROIL
• SELF-CLEAN (primary ovens)
• Extra Large Oven fits Full Size Commercial Cookie Sheets (primary oven)
• Infrared Broiler Under Glass (primary oven)
• Integrated Moto-Rotis Rotisserie system (primary oves)
• 5 rack positions
• Flex-Roll oven racks for smooth operation
• Removable Door with Heavy Duty Hinges
• Front located Gas Shut-Off Valve and Electrical Disconnect
• 30,000 BTU oven burner for uniform baking (primary oven)
• 18,000 BTU Infrared Broil Burner Under Glass with Inconel (primary oven)
• 22,000 BTU oven burner for uniform baking ( companion oven)
• Stay-Cool™ die cast, chrome plated metal knobs
• Professional style heavy duty cast iron grates with easy to clean matte porcelain finish
Electrical Information
Information
120
Dimensions
Class Width
60"
Width
59.87 inch(es) / 152.08 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
28.37 inch(es) / 72.07 cm
Weight
560 lb(s) / 254.01 kg
Additional Dimensions
• Primary Oven Dimensions: 27" W x 15" H x 21"
• Companion Oven Dimensions: 18" W X 14" H X 21" D
• Cutout Dimension: 60-1/8"W X 24"D (std)
• For more information refer to dimension guide
• Companion Oven Dimensions: 18" W X 14" H X 21" D
• Cutout Dimension: 60-1/8"W X 24"D (std)
• For more information refer to dimension guide
Shipping Dimensions
Weight
600.01 lb(s) / 272.16 kg
Warranty
Warranty
• ONE (1) Year full parts and labor covers entire product with the exception of painted or decorative parts listed below*. (Light bulbs covered for 60 days after installation.) Standard shipping only. Expedited shipping will be at customers' expense
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
