Features
STAY-COOL™ KNOBS
Die cast chrome-plated metal knobs with black trims.
INFRARED BROIL BURNER
Infrared Broil burner for quick searing or indoor grilling.
EZ-GLIDES™
Full extension removable drip trays mounted on ball bearing rails.
Specifications
General
Series Name
CULINARIAN
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
4
Burners/Elements Output
• Three (3) 25,000 BTU open style burners all turn down to a True Simmer
• One (1) 8,000 BTU Small Pan Burner turns down to an extra low simmer
• One (1) 8,000 BTU Small Pan Burner turns down to an extra low simmer
Burners
Open
Oven
Capacity (cu. ft.)
4.9
Number of Ovens
Single
Features
Convection
Yes
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
No
Additional Information
• Natural Gas: 7" WC input pressure: 5" WC pressure regulator provided
• Liquid Propane: 11" WC input pressure: 10" WC pressure regulator provided
• Manual clean
• Convection oven
• BAKE
• CONVECTION BAKE
• BROIL
• 30,000 BTU oven burner for uniform baking
• 18,000 BTU Infrared Broil burner with Inconel Mesh construction
• Titanium speck porcelain oven interior
• 5 Rack Positions w/ 2 Heavy Duty Racks provided
• Broil pan provided
• 1-1/4" diameter professional-style handle
• Heavy-duty oven door hinges
• Extra large viewing window
• Bright 40W oven lights
• Stay-Cool™ die cast, chrome plated metal knobs
• Professional stye heavy duty cast iron grates with easy to clean matte porcelain finish
• Full extension Drip Trays on EZ-Glides™
• All burners have auto ignition and re-ignition
• Liquid Propane: 11" WC input pressure: 10" WC pressure regulator provided
• Manual clean
• Convection oven
• BAKE
• CONVECTION BAKE
• BROIL
• 30,000 BTU oven burner for uniform baking
• 18,000 BTU Infrared Broil burner with Inconel Mesh construction
• Titanium speck porcelain oven interior
• 5 Rack Positions w/ 2 Heavy Duty Racks provided
• Broil pan provided
• 1-1/4" diameter professional-style handle
• Heavy-duty oven door hinges
• Extra large viewing window
• Bright 40W oven lights
• Stay-Cool™ die cast, chrome plated metal knobs
• Professional stye heavy duty cast iron grates with easy to clean matte porcelain finish
• Full extension Drip Trays on EZ-Glides™
• All burners have auto ignition and re-ignition
Electrical Information
Information
120
Certifications and Approvals
Sabbath/Star-K
No
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
28.37 inch(es) / 72.07 cm
Weight
350.01 lb(s) / 158.76 kg
Additional Dimensions
• Cutout Dimension: 30-1/8"W X 24"D (std)
• Oven Dimensions: 27" W x 15" H x 21"
• For more information refer to dimension guide
• Oven Dimensions: 27" W x 15" H x 21"
• For more information refer to dimension guide
Shipping Dimensions
Weight
380.01 lb(s) / 172.37 kg
Warranty
Warranty
• ONE (1) Year full parts and labor covers entire product with the exception of painted or decorative parts listed below*. (Light bulbs covered for 60 days after installation.) Standard shipping only. Expedited shipping will be at customers' expense
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
