Features
POWER-FLO OPEN BURNER
Capital Cooking Equipment designs and manufactures the most powerful burners on the home appliance market. Each burner produces 25,000 BTUs of searing heat and also turns down to
a delicate, consistent simmer, offering precise control. Perfect for the cooking connoisseur.
18,000 BTU THERMO-GRIDDLE-PLATE™
3/8" thick 12” width stainless steel thermostatically controlled.
Additional Features
STAY-COOL™ KNOBS
Die cast chrome-plated metal knobs with black trims.
Specifications
General
Series Name
Culinarian
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
4
Burners/Elements Output
• Three (3) 25, 000 BTU open style burners turn down to a True Simmer
• One (1) 8,000 BTU Small Pan Burner turns down to an extra low simmer
• One (1) 12 inch wide 18,000 BTU Stainless Steel Griddle Plate with Thermostatic Control and Stainless Steel Cover
• 30,000 BTU oven burner for uniform baking
• 18,000 BTU Infrared Broil burner with Inconel Mesh construction
• One (1) 8,000 BTU Small Pan Burner turns down to an extra low simmer
• One (1) 12 inch wide 18,000 BTU Stainless Steel Griddle Plate with Thermostatic Control and Stainless Steel Cover
• 30,000 BTU oven burner for uniform baking
• 18,000 BTU Infrared Broil burner with Inconel Mesh construction
Burners
Open
Oven
Capacity (cu. ft.)
4.9
Number of Ovens
Single
Features
Convection
Yes
Oven Light
Yes
Electrical Information
Information
120 volts
Dimensions
Class Width
36"
Width
35.87 inch(es) / 91.12 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
28.37 inch(es) / 72.07 cm
Weight
479.99 lb(s) / 217.72 kg
Additional Dimensions
• Shipping Dimensions: 40" W x 48" H x 34" D
• Oven Dimensions: 27" W x 15" H x 21"
• Cutout Dimension: 36-1/8"W X 24"D
• Oven Dimensions: 27" W x 15" H x 21"
• Cutout Dimension: 36-1/8"W X 24"D
Shipping Dimensions
Weight
520 lb(s) / 235.87 kg
Warranty
Warranty
Limited 1 year parts and labor
Documents
