Features
OPEN BURNERS
Each burner produces 25,000 BTUs
of searing heat and also turns down to
a delicate, consistent simmer, offering
precise control. Perfect for the cooking
connoisseur.
Additional Features
EZ-GLIDES™
Full extension removable drip trays mounted on ball bearing rails.
Specifications
General
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
6
Burners/Elements Output
• Three 25, 000 BTU open style burners turn down to a True Simmer
• One 8,000 BTU Small Pan Burner turns down to an extra low simmer
• 24 inch wide with two (2) 18,000 BTU BBQ Grill Burners with
• One 8,000 BTU Small Pan Burner turns down to an extra low simmer
• 24 inch wide with two (2) 18,000 BTU BBQ Grill Burners with
Burner/Element Size
24" BBQ Grill
Burners
Open
Other
Grill
Oven
Capacity (cu. ft.)
7.4
Number of Ovens
Double
Features
Convection
Yes
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
No
Additional Information
• BAKE (Both Ovens)
• BROIL (Large Oven only)
• CONVECTION BAKE (Both Ovens)
• Primary Oven fits Full Size Commercial Cookie Sheet
• Companion Oven fits Commercial Half Sheets
• Flush oven bottoms for extra capacity (both ovens)
• Infrared Broiler (Large Oven only)
• 5 rack positions
• Removable Door with Heavy Duty Hinges
• Compatible with Rear Floor Mount Gas Line Input
• 5 Rack Positions w/ 2 Heavy Duty Racks provided
• 1-1/4" diameter professional-style handle
• Bright 40W oven lights
• Stay-Cool™ die cast, chrome plated metal knobs
• Professional stye heavy duty cast iron grates with easy to clean matte porcelain finish
• Full extension Drip Trays on EZ-Glides
• Flush Island Friendly Trim
• All burner have auto ignition and re-ignition
• Natural Gas: 7" WC input pressure: 5" WC pressure regulator provided
• Liquid Propane: 11" WC input pressure: 10" WC pressure regulator provided
• BROIL (Large Oven only)
• CONVECTION BAKE (Both Ovens)
• Primary Oven fits Full Size Commercial Cookie Sheet
• Companion Oven fits Commercial Half Sheets
• Flush oven bottoms for extra capacity (both ovens)
• Infrared Broiler (Large Oven only)
• 5 rack positions
• Removable Door with Heavy Duty Hinges
• Compatible with Rear Floor Mount Gas Line Input
• 5 Rack Positions w/ 2 Heavy Duty Racks provided
• 1-1/4" diameter professional-style handle
• Bright 40W oven lights
• Stay-Cool™ die cast, chrome plated metal knobs
• Professional stye heavy duty cast iron grates with easy to clean matte porcelain finish
• Full extension Drip Trays on EZ-Glides
• Flush Island Friendly Trim
• All burner have auto ignition and re-ignition
• Natural Gas: 7" WC input pressure: 5" WC pressure regulator provided
• Liquid Propane: 11" WC input pressure: 10" WC pressure regulator provided
Drawer Features
Indicator Light
No
Electrical Information
Information
120
Dimensions
Class Width
48"
Width
47.87 inch(es) / 121.6 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
28.37 inch(es) / 72.07 cm
Weight
560 lb(s) / 254.01 kg
Additional Dimensions
• Cutout Dimension: 48-1/8"W X 24"D (std)
• Primary Oven Dimensions: 27" W x 15" H x 21"
• Companion Oven Dimensions: 15" W X 15" H X 21" D
• For more information refer to dimension guide
• Primary Oven Dimensions: 27" W x 15" H x 21"
• Companion Oven Dimensions: 15" W X 15" H X 21" D
• For more information refer to dimension guide
Shipping Dimensions
Weight
600.01 lb(s) / 272.16 kg
Warranty
Warranty
• ONE (1) Year full parts and labor covers entire product with the exception of painted or decorative parts listed below*. (Light bulbs covered for 60 days after installation.) Standard shipping only. Expedited shipping will be at customers' expense
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
