Features
OPEN BURNERS
Each burner produces 25,000 BTUs
of searing heat and also turns down to
a delicate, consistent simmer, offering
precise control. Perfect for the cooking
connoisseur.
Additional Features
STAY-COOL™ KNOBS
Die cast chrome-plated metal knobs with black trims.
THERMO-GRIDDLE™
Solid stainless steel thermostatically controlled griddle plate gives you precise control over the griddle area.
EZ-GLIDES™
Full extension removable drip trays mounted on ball bearing rails.
Specifications
General
Series Name
CULINARIAN
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
6
Burners/Elements Output
• Three 25, 000 BTU open style burners turn down to a True Simmer
• One 8,000 BTU Small Pan Burner turns down to an extra low simmer
• 12 inch wide 18,000 BTU BBQ Grill Burner with Cast Iron Porcelain Coated Grates Hybrid Radiants and Stainless Steel Cover
• 12 inch wide 18,000 BTU Stainless Steel Griddle Plate with Thermostatic Control and Stainless Steel Cover
• One 8,000 BTU Small Pan Burner turns down to an extra low simmer
• 12 inch wide 18,000 BTU BBQ Grill Burner with Cast Iron Porcelain Coated Grates Hybrid Radiants and Stainless Steel Cover
• 12 inch wide 18,000 BTU Stainless Steel Griddle Plate with Thermostatic Control and Stainless Steel Cover
Burner/Element Size
• 12 inch wide BBQ Grill
• 12 inch wide Stainless Steel Griddle Plate
• 12 inch wide Stainless Steel Griddle Plate
Burners
Open
Other
Grill,Griddle
Oven
Capacity (cu. ft.)
• Large Oven: 4.9
• Small Oven: 2.7
• Total Capacity: 7.6
• Small Oven: 2.7
• Total Capacity: 7.6
Number of Ovens
Double
Features
Control Lock
No
Convection
Yes
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
No
Additional Information
• Manual clean (Both ovens)
• Convection oven (Both ovens)
• BAKE (Both ovens)
• CONVECTION BAKE (Both ovens)
• BROIL (Large oven)
• 30,000 BTU oven burner for uniform baking (Large oven)
• 18,000 BTU Infrared Broil burner with Inconel Mesh construction (Large oven)
• Titanium speck porcelain oven interior (Both ovens)
• 5 Rack Positions w/ 2 Heavy Duty Racks provided (Both ovens)
• Broil pan provided
• 1-1/4" diameter professional-style handle (Both ovens)
• Heavy-duty oven door hinges (Both ovens)
• Extra large viewing window (Both ovens)
• Bright 40W oven lights (Both ovens)
• Stay-Cool™ die cast, chrome plated metal knobs
• Full extension Drip Trays on EZ-Glides
• Natural Gas: 7" WC input pressure: 5" WC pressure regulator provided
• Liquid Propane: 11" WC input pressure: 10" WC pressure regulator provided
• Convection oven (Both ovens)
• BAKE (Both ovens)
• CONVECTION BAKE (Both ovens)
• BROIL (Large oven)
• 30,000 BTU oven burner for uniform baking (Large oven)
• 18,000 BTU Infrared Broil burner with Inconel Mesh construction (Large oven)
• Titanium speck porcelain oven interior (Both ovens)
• 5 Rack Positions w/ 2 Heavy Duty Racks provided (Both ovens)
• Broil pan provided
• 1-1/4" diameter professional-style handle (Both ovens)
• Heavy-duty oven door hinges (Both ovens)
• Extra large viewing window (Both ovens)
• Bright 40W oven lights (Both ovens)
• Stay-Cool™ die cast, chrome plated metal knobs
• Full extension Drip Trays on EZ-Glides
• Natural Gas: 7" WC input pressure: 5" WC pressure regulator provided
• Liquid Propane: 11" WC input pressure: 10" WC pressure regulator provided
Electrical Information
Information
120
Certifications and Approvals
Sabbath/Star-K
Yes
Dimensions
Class Width
48"
Width
47.87 inch(es) / 121.6 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
28.37 inch(es) / 72.07 cm
Weight
560 lb(s) / 254.01 kg
Additional Dimensions
• Primary oven cavity: 27"W X 21"D X 15"H
• Companion oven cavity: 15"W X 21"D X 15"H
• For more information refer to dimension guide
• Companion oven cavity: 15"W X 21"D X 15"H
• For more information refer to dimension guide
Shipping Dimensions
Weight
600.01 lb(s) / 272.16 kg
Warranty
Warranty
• ONE (1) Year full parts and labor covers entire product with the exception of painted or decorative parts listed below*. (Light bulbs covered for 60 days after installation.) Standard shipping only. Expedited shipping will be at customers' expense
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
