Features
FLEX-ROLL™ OVEN RACKS
Oven racks for smooth operation in self-clean ranges.
OPEN BURNERS
Each burner produces 25,000 BTUs
of searing heat and also turns down to
a delicate, consistent simmer, offering
precise control. Perfect for the cooking
connoisseur.
Additional Features
EZ-GLIDES™
Full extension removable drip trays mounted on ball bearing rails.
Specifications
General
Series Name
CULINARIAN
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
7
Burners/Elements Output
• Five 25, 000 BTU open style burners turn down to a True Simmer
• One 8,000 BTU Small Pan Burner turns down to an extra low simmer
• 18,000 BTU BBQ Grill Burner with Cast Iron Porcelain Coated Grates Hybrid Radiants and Stainless Steel Cover
• One 8,000 BTU Small Pan Burner turns down to an extra low simmer
• 18,000 BTU BBQ Grill Burner with Cast Iron Porcelain Coated Grates Hybrid Radiants and Stainless Steel Cover
Burner/Element Size
12" BBQ Grill
Burners
Open
Other
Grill
Oven
Capacity (cu. ft.)
• Large Oven : 4.9
• Small Oven : 2.7
• Total Capacity : 7.6
• Small Oven : 2.7
• Total Capacity : 7.6
Number of Ovens
Double
Features
Convection
Yes
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
No
Additional Information
• BAKE (Both Ovens)
• BROIL (Primary Oven only)
• CONVECTION BAKE (Both Ovens)
• Primary Oven fits Full Size Commercial Cookie Sheet
• Companion Oven fits Commercial Half Sheets
• Flush oven bottoms for extra capacity (both ovens)
• Infrared Broiler (Primary Oven only)
• 5 rack positions
• Compatible with Rear Floor Mount Gas Line Input
• 30,000 BTU oven burner for uniform baking (Primary Oven)
• 18,000 BTU Infrared Broil burner with Inconel Mesh (Primary Oven)
• 15,000 BTU oven burner for uniform baking (Companion Oven)
• Stay-Cool™ die cast, chrome plated metal knobs
• Professional stye heavy duty cast iron grates with easy to clean matte porcelain finish
• BROIL (Primary Oven only)
• CONVECTION BAKE (Both Ovens)
• Primary Oven fits Full Size Commercial Cookie Sheet
• Companion Oven fits Commercial Half Sheets
• Flush oven bottoms for extra capacity (both ovens)
• Infrared Broiler (Primary Oven only)
• 5 rack positions
• Compatible with Rear Floor Mount Gas Line Input
• 30,000 BTU oven burner for uniform baking (Primary Oven)
• 18,000 BTU Infrared Broil burner with Inconel Mesh (Primary Oven)
• 15,000 BTU oven burner for uniform baking (Companion Oven)
• Stay-Cool™ die cast, chrome plated metal knobs
• Professional stye heavy duty cast iron grates with easy to clean matte porcelain finish
Electrical Information
Information
120
Dimensions
Class Width
48"
Width
47.87 inch(es) / 121.6 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
28.37 inch(es) / 72.07 cm
Weight
560 lb(s) / 254.01 kg
Additional Dimensions
• Primary Oven Dimensions: 27" W x 15" H x 21"
• Companion Oven Dimensions: 15" W X 15" H X 21" D
• Cutout Dimension: 48-1/8"W X 24"D (std)
• Companion Oven Dimensions: 15" W X 15" H X 21" D
• Cutout Dimension: 48-1/8"W X 24"D (std)
Shipping Dimensions
Weight
600.01 lb(s) / 272.16 kg
Warranty
Warranty
• ONE (1) Year full parts and labor covers entire product with the exception of painted or decorative parts listed below*. (Light bulbs covered for 60 days after installation.) Standard shipping only. Expedited shipping will be at customers' expense
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
