Features
OPEN BURNERS
Each burner produces 25,000 BTUs
of searing heat and also turns down to
a delicate, consistent simmer, offering
precise control. Perfect for the cooking
connoisseur.
Additional Features
EZ-GLIDES™
Full extension removable drip trays mounted on ball bearing rails.
STAY-COOL™ KNOBS
Die cast chrome-plated metal knobs with black trims.
INFRA-BROIL™
Gas infrared broiler beneath glass generates 18,000 BTUs of power. And the radiant glass makes clean-ups a snap.
Specifications
General
Series Name
CULINARIAN
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
8
Burners/Elements Output
• BAKE (Both ovens)
• BROIL (Large oven only)
• CONVECTION BAKE (Both ovens)
• Primary Oven fits Full Size Commercial Cookie Sheet
• Companion Oven fits Commercial Half Sheets
• Flush oven bottoms for extra capacity (both ovens)
• Infrared Broiler (Large oven only)
• 5 rack positions
• Compatible with Rear Floor Mount Gas Line Input
• 30,000 BTU oven burner for uniform baking (Large oven only)
• 18,000 BTU Infrared Broil burner with Inconel Mesh (Large oven only)
• 15,000 BTU oven burner for uniform baking (Small oven)
• Stay-Cool™ die cast, chrome plated metal knobs
• Professional stye heavy duty cast iron grates with easy to clean matte porcelain finish
• Full extension Drip Trays on EZ-Glides
• Natural Gas: 7" WC input pressure: 5" WC pressure regulator provided
• Liquid Propane: 11" WC input pressure: 10" WC pressure regulator provided
• Bright 40W oven lights
• BROIL (Large oven only)
• CONVECTION BAKE (Both ovens)
• Primary Oven fits Full Size Commercial Cookie Sheet
• Companion Oven fits Commercial Half Sheets
• Flush oven bottoms for extra capacity (both ovens)
• Infrared Broiler (Large oven only)
• 5 rack positions
• Compatible with Rear Floor Mount Gas Line Input
• 30,000 BTU oven burner for uniform baking (Large oven only)
• 18,000 BTU Infrared Broil burner with Inconel Mesh (Large oven only)
• 15,000 BTU oven burner for uniform baking (Small oven)
• Stay-Cool™ die cast, chrome plated metal knobs
• Professional stye heavy duty cast iron grates with easy to clean matte porcelain finish
• Full extension Drip Trays on EZ-Glides
• Natural Gas: 7" WC input pressure: 5" WC pressure regulator provided
• Liquid Propane: 11" WC input pressure: 10" WC pressure regulator provided
• Bright 40W oven lights
Burners
Open
Oven
Capacity (cu. ft.)
• Large Oven : 4.9
• Small Oven : 2.7
• Total Capacity : 7.6
• Small Oven : 2.7
• Total Capacity : 7.6
Number of Ovens
Double
Features
Convection
Yes
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
No
Additional Information
• Powerful 25,000 BTU Open Burners offer high-heat sear and turn down to provide a 140° F simmer;
• Auto-ignition and re-ignition on all burners;
• Heavy-duty continuous grates for easy mobility on the rangetop;
• Oven has five rack positions for the two racks provided;
• Bake, broil and convection bake cooking available;
• Flush oven bottom and rear trim for island friendly installations;
• Stay-Cool die cast chrome plated metal knobs with black trim offer precise control;
• Auto-ignition and re-ignition on all burners;
• Heavy-duty continuous grates for easy mobility on the rangetop;
• Oven has five rack positions for the two racks provided;
• Bake, broil and convection bake cooking available;
• Flush oven bottom and rear trim for island friendly installations;
• Stay-Cool die cast chrome plated metal knobs with black trim offer precise control;
Electrical Information
Information
120
Dimensions
Class Width
48"
Width
47.87 inch(es) / 121.6 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
28.37 inch(es) / 72.07 cm
Weight
560 lb(s) / 254.01 kg
Additional Dimensions
• Primary Oven Dimensions: 27" W x 15" H x 21"
• Companion Oven Dimensions: 15" W X 15" H X 21" D
• Cutout Dimension: 48-1/8"W X 24"D (std)
• For more information refer to dimension guide
• Companion Oven Dimensions: 15" W X 15" H X 21" D
• Cutout Dimension: 48-1/8"W X 24"D (std)
• For more information refer to dimension guide
Shipping Dimensions
Weight
600.01 lb(s) / 272.16 kg
Warranty
Warranty
• ONE (1) Year full parts and labor covers entire product with the exception of painted or decorative parts listed below*. (Light bulbs covered for 60 days after installation.) Standard shipping only. Expedited shipping will be at customers' expense
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
