Features
POWER-FLO BURNERS 19,000 BTU
Capital exclusive feature: Power-Flo burners 19,000 BTU to a low delicate simmer.
POWER-FLO™ BURNERS (19,000 BTU - 140 DEG. SIMMER)
Capital exclusive feature: Optional cabernet red knobs Power-Flo™ burners.
19,000 BTU - 140 deg. simmer.
Additional Features
STAY-COOL™ KNOBS
Die cast chrome-plated metal knobs with black trims.
INFRA-BROIL™
Gas infrared broiler beneath glass generates 18,000 BTUs of power. And the radiant glass makes clean-ups a snap.
Specifications
General
Series Name
PRECISION
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
4
Burners/Elements Output
4 Buners : 19,000 BTU Power-Flo™
Burners
Sealed
Oven
Capacity (cu. ft.)
4.9
Number of Ovens
Single
Features
Convection
Yes
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
No
Additional Information
• Manual clean
• Convection oven
• BAKE
• CONVECTION BAKE
• BROIL
• 30,000 BTU oven burner for uniform baking
• 18,000 BTU Infrared Broil burner with Inconel Mesh construction
• Titanium speck porcelain oven interior
• 5 Rack Positions w/ 2 Heavy Duty Racks provided
• Broil pan provided
• 1-1/4" diameter professional-style handle
• Heavy-duty oven door hinges
• Extra large viewing window
• Bright 40W oven lights
• Stay-Cool™ die cast, chrome plated metal knobs
• Auto-ignition/re-ignition on all burners
• Smooth-top continuous cast iron grates with easy to clean matte porcelain finish
• Convection oven
• BAKE
• CONVECTION BAKE
• BROIL
• 30,000 BTU oven burner for uniform baking
• 18,000 BTU Infrared Broil burner with Inconel Mesh construction
• Titanium speck porcelain oven interior
• 5 Rack Positions w/ 2 Heavy Duty Racks provided
• Broil pan provided
• 1-1/4" diameter professional-style handle
• Heavy-duty oven door hinges
• Extra large viewing window
• Bright 40W oven lights
• Stay-Cool™ die cast, chrome plated metal knobs
• Auto-ignition/re-ignition on all burners
• Smooth-top continuous cast iron grates with easy to clean matte porcelain finish
Electrical Information
Information
120
Dimensions
Class Width
30"
Width
29.88 inch(es) / 75.90 cm
Height
36.75 inch(es) / 93.35 cm
Depth (Without Handles)
28.47 inch(es) / 72.32 cm
Weight
350.01 lb(s) / 158.76 kg
Additional Dimensions
• Primary Oven Dimensions: 27" W x 15" H x 21
• Cutout Dimension: 30-1/8"W X 24"D (std)
• For more information refer to dimension guide
• Cutout Dimension: 30-1/8"W X 24"D (std)
• For more information refer to dimension guide
Shipping Dimensions
Weight
380.01 lb(s) / 172.37 kg
Warranty
Warranty
• ONE (1) Year full parts and labor covers entire product with the exception of painted or decorative parts listed below*. (Light bulbs covered for 60 days after installation.) Standard shipping only. Expedited shipping will be at customers' expense
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
