Features
30,000 BTU POWER-WOK™
POWER-FLO™ BURNERS (19,000 BTU - 140 DEG. SIMMER)
Capital exclusive feature: Optional cabernet red knobs Power-Flo™ burners.
19,000 BTU - 140 deg. simmer.
Additional Features
STAY-COOL™ KNOBS
Die cast chrome-plated metal knobs with black trims.
Specifications
General
Series Name
PRECISION
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
5
Burners/Elements Output
• Four (4) 19,000 BTU Power-Flo™ sealed burners turn down to Tru Simmer
• One (1) 25,000 BTU Power-Wok Burner
• One (1) 25,000 BTU Power-Wok Burner
Other
Wok
Oven
Capacity (cu. ft.)
4.9
Number of Ovens
Single
Features
Convection
Yes
Delay Bake/Start
No
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Additional Information
• Convection Oven
• Large Oven Accomadates 26"x 18" Commercial Size Pan
• 18,000 BTU Infrared Broiler
• 30,000 BTU Oven for Uniform Baking
• Adjustable Rear Casters for Easy Installation
• Adjustable Front Legs for Easy Leveling
• Titanium Speck Porcelain Oven Interior
• 25-Watt Bright Oven Lights
• Large Viewing Window
• 4 Rack Positions w/ 3 Racks Provided (1 Rack with Broil Pan Position)
• Broil Pan Provided
• 1-1/4" Thick Professional-Style Handle
• Heavy-Duty Oven Door Hinges
• Extra Large Viewing Window w/ Embossed Design
• Oven Modes : Bake, Broil, Convection Bake, Convection Broil, Open-Door Broil
• Large Oven Accomadates 26"x 18" Commercial Size Pan
• 18,000 BTU Infrared Broiler
• 30,000 BTU Oven for Uniform Baking
• Adjustable Rear Casters for Easy Installation
• Adjustable Front Legs for Easy Leveling
• Titanium Speck Porcelain Oven Interior
• 25-Watt Bright Oven Lights
• Large Viewing Window
• 4 Rack Positions w/ 3 Racks Provided (1 Rack with Broil Pan Position)
• Broil Pan Provided
• 1-1/4" Thick Professional-Style Handle
• Heavy-Duty Oven Door Hinges
• Extra Large Viewing Window w/ Embossed Design
• Oven Modes : Bake, Broil, Convection Bake, Convection Broil, Open-Door Broil
Drawer Features
Indicator Light
No
Electrical Information
Information
120
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
28.37 inch(es) / 72.07 cm
Weight
380.01 lb(s) / 172.37 kg
Additional Dimensions
• Oven Dimensions: 27" W x 15" H x 21"
• Cutout Dimension: 30-1/8"W X 24"D (std)
• For more information refer to dimension guide
• Cutout Dimension: 30-1/8"W X 24"D (std)
• For more information refer to dimension guide
Shipping Dimensions
Weight
350.01 lb(s) / 158.76 kg
Warranty
Warranty
• ONE (1) Year full parts and labor covers entire product with the exception of painted or decorative parts listed below*. (Light bulbs covered for 60 days after installation.) Standard shipping only. Expedited shipping will be at customers' expense
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
• *Painted and decorative parts will be warranted for 90 days from date of original purchase. Any damages or defects must be reported within this timeframe. Replacement painted parts may have slight color variations from the original parts due to normal manufacturing variables
• FIVE (5) Years limited part replacement warranty. Covers part replacement, as noted below due to malfunction during normal operation
