Features
STAINLESS STEEL BURNERS (25,000BTU)
The precision ported U-shaped stainless steel burners are rated at a massive 25,000BTU each, offering premium quality and performance. A heat shield directs heat upwards maximizing heating efficiency.
CERAMIC RADIANT TECHNOLOGY.
A layer of ceramic rods provides intense yet even heat. It gives a consistent grilling surface, with controlled heat rather than direct fire.
DIRECT BURNER IGNITION.
An ergonomic ignition solution, where burners are lit directly from the corresponding knobs.
TEMPERATURE GAUGE - ZERO TO SEAR.
Go from zero to sear with DCS Grills’ new built-in temperature gauge. It lets you know exactly how hot the grill is, even when the hood is down.
Specifications
General
Series Name
Series 7
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Type
Built-In
Fuel Type
Natural Gas
Cooking Area
Total Cooking Area
748 in²
Primary Area
553 in²
Secondary Area
195 in²
Cooking System
Burners
2
Maximum Power
50000 BTU
Main Burner Output
25000 BTU
Features
Warming Rack
Yes
Additional Information
• Full surface searing
• Hood temperature gauge
• Ignition system: Spark
• Metal dials
• 304 grade stainless steel
• Weather resistant
• 9V Battery for Ignition
• Hood temperature gauge
• Ignition system: Spark
• Metal dials
• 304 grade stainless steel
• Weather resistant
• 9V Battery for Ignition
Accessories
Optional
• Built-in grill cover: ACBI-30
• Insulated jacket: BGB30-IJS (optional)
• On cart grill cover: ACC-30
• Optional cart mount: CAD1-30 / BGB30-CSS
• Insulated jacket: BGB30-IJS (optional)
• On cart grill cover: ACC-30
• Optional cart mount: CAD1-30 / BGB30-CSS
Dimensions
Grill Size
30"
Overall Width
30 inch(es) / 76.2 cm
Overall Height
24.25 inch(es) / 61.6 cm
Overall Depth
26.62 inch(es) / 67.62 cm
Additional Dimensions
• Cutout depth (proud): 22 3/4"
• Cutout height (proud): 10 1/8"
• Cutout width (proud): 28 1/2"
• Cutout height (proud): 10 1/8"
• Cutout width (proud): 28 1/2"
