Specifications
General
Series Name
Plane NRS
Blower Included
Yes
Airflow
600 CFM
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Technologies
• NRS Technology
• SRS Speed Reduction System
• SRS Speed Reduction System
Additional Information
• Perimeter suction
• Control: Electronic control
• Remote control (optional)
• Ducting type: External ducting/Recirculating
• Installation type: Wall
• Lighting: Dynamic Light (2700K - 5600K)
• Dimmable lighting
• Strip LED
• Filters: Metallic grease filter, removable and washable
• Carbon.Zeo Microtech renewable filter (optional)
• Notes: Recommended mounting height from cooking surface to hood bottom: 24" - 35"
• Control: Electronic control
• Remote control (optional)
• Ducting type: External ducting/Recirculating
• Installation type: Wall
• Lighting: Dynamic Light (2700K - 5600K)
• Dimmable lighting
• Strip LED
• Filters: Metallic grease filter, removable and washable
• Carbon.Zeo Microtech renewable filter (optional)
• Notes: Recommended mounting height from cooking surface to hood bottom: 24" - 35"
Electrical Information
Information
• Maximum consumption: 340 W
• Voltage/Frequency: 110-120V 60Hz
• Connection type: Hood comes standard with NEMA 5-15P power cord
• Voltage/Frequency: 110-120V 60Hz
• Connection type: Hood comes standard with NEMA 5-15P power cord
Dimensions
Class Width
48"
Width
47.17 inch(es) / 119.8 cm
Height
20.83 inch(es) / 52.9 cm
Depth
19.29 inch(es) / 49.0 cm
Weight
80.01 lb(s) / 36.29 kg
Shipping Dimensions
Width
53 inch(es) / 134.62 cm
Height
27 inch(es) / 68.58 cm
Depth
29 inch(es) / 73.66 cm
Weight
95 lb(s) / 43.09 kg
