Features
PAIRS WITH OTHER DISHDRAWER™ MODELS
Pairs seamlessly with other DishDrawer™ Dishwasher models or works alone to support flexible kitchen design.
TRUE HALF-LOAD WASHING
Designed for true half-load washing, with flexible racking that fits dinner plates up to 11" high.
VERSATILE WASH CYCLES AND FAN-ASSISTED DRYING
Versatile wash cycles and modifiers ensure clean results, while fan-assisted drying helps leave dishes ready to use.
SMARTHQ™ CONNECTIVITY
SmartHQ™ connectivity offers remote control and notifications through the app.
Specifications
General
Series Name
Series 7 Contemporary
Type
Built-In
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Place Settings
7
Silence Rating
43 dB
Cycle Information
Number of Cycles
6
Wash Cycles
• Eco — for normally soiled dishes (default)
• Heavy — for heavily soiled pots, pans and dishes
• Medium — for quite heavily soiled dishes or food left overnight
• Light — for very lightly soiled dishes
• 60 Min — for quite heavily soiled dishes, no drying
• Hygiene — raises the rinse temperature to 158°F to sanitize
• Heavy — for heavily soiled pots, pans and dishes
• Medium — for quite heavily soiled dishes or food left overnight
• Light — for very lightly soiled dishes
• 60 Min — for quite heavily soiled dishes, no drying
• Hygiene — raises the rinse temperature to 158°F to sanitize
Options
• Dry+ — increases the final rinse temperature and the length of the drying phase
• Gentle — lowers the water temperature and pressure
• Intensive — increases the water pressure and the length of the cycle
• Gentle — lowers the water temperature and pressure
• Intensive — increases the water pressure and the length of the cycle
Features
Technologies
• DishDrawer™ — single drawer that works alone or pairs with other DishDrawer™ models
• SmartDrive™ Technology
• Variable Wash Pressure Technology
• SmartHQ™ App — remote operation, alerts and notifications, energy consumption monitoring and software updates
• SmartDrive™ Technology
• Variable Wash Pressure Technology
• SmartHQ™ App — remote operation, alerts and notifications, energy consumption monitoring and software updates
Delay Start Information
Energy saving delay start option of up to 12 hours
Delay Start
Yes
Control Lock
Yes
Filtration System
Yes
Silverware Basket
Yes
Wi-Fi
Yes
Additional Information
• Single DishDrawer™ dishwasher — true half-load dish care
• Pairs with other DishDrawer™ models or installs on its own
• Accommodates round plates up to 11"
• Adjustable height, foldable cup racks
• Fold down tines
• Pitch adjustable tines
• Wine glass supports
• Fan assisted drying
• Drawer Dry — a low-power fan runs after each wash cycle to dry the appliance
• Three-stage filtration system
• Flood protection
• Flow through detergent dispenser
• Motor type: BLDC
• Soft close drawer
• Pocket handle
• Black touch concealed interface
• Electronic fault/diagnostic indicator
• End of cycle beeps
• Play + Pause button
• Rinse aid indicator light
• Can be installed at counter height for easy access with minimal bending
• Inlet water temperature: 140°F
• Water pressure: 30 kPa - 1000 kPa
• Water supply: 3/8" to suit male compression fitting
• Pairs with other DishDrawer™ models or installs on its own
• Accommodates round plates up to 11"
• Adjustable height, foldable cup racks
• Fold down tines
• Pitch adjustable tines
• Wine glass supports
• Fan assisted drying
• Drawer Dry — a low-power fan runs after each wash cycle to dry the appliance
• Three-stage filtration system
• Flood protection
• Flow through detergent dispenser
• Motor type: BLDC
• Soft close drawer
• Pocket handle
• Black touch concealed interface
• Electronic fault/diagnostic indicator
• End of cycle beeps
• Play + Pause button
• Rinse aid indicator light
• Can be installed at counter height for easy access with minimal bending
• Inlet water temperature: 140°F
• Water pressure: 30 kPa - 1000 kPa
• Water supply: 3/8" to suit male compression fitting
Electrical Information
Information
• Supply Voltage: 110 - 120 V
• Supply Frequency: 60 Hz
• Amperage: 5 A (dedicated circuit)
• Rated Power: 600 W
• Supply Frequency: 60 Hz
• Amperage: 5 A (dedicated circuit)
• Rated Power: 600 W
Certifications and Approvals
Energy Star Certified
Yes
NSF® Certified
Yes
Dimensions
Class Width
24"
Width
23.56 inch(es) / 59.84 cm
Height (Min.)
16.13 inch(es) / 40.97 cm
Depth (Without Handle)
21.75 inch(es) / 55.25 cm
Weight
72 lb(s) / 32.66 kg
Additional Dimensions
• Overall Depth (including 0.81 in drawer panel): 22.56 in
• Panel Height: 15.5 in
• Cavity Minimum Height: 16.25 in
• Cavity Width: 23.63 - 24 in
• Cavity Minimum Depth: 22.63 in
• Panel Height: 15.5 in
• Cavity Minimum Height: 16.25 in
• Cavity Width: 23.63 - 24 in
• Cavity Minimum Depth: 22.63 in
Shipping Dimensions
Width
27.56 inch(es) / 70 cm
Height
20.5 inch(es) / 52.07 cm
Depth
28.38 inch(es) / 72.09 cm
Weight
88.01 lb(s) / 39.92 kg
Warranty
Warranty
2-year manufacturer's limited warranty, parts and labour
