Features
QUIET AND EFFECTIVE (15MIN)
Featuring perimeter extraction, four fan speeds, and a boost function, this range hood provides powerful extraction to quickly remove odors and steam. Odors can linger in the kitchen well after cooking is finished so the timer keeps the hood working for up to 15 minutes before automatically turning off.
SIMPLE CONTROLS (INTUITIVE CONTROL PANEL)
The intuitive control panel responds to the touch of your finger. LED strip lighting illuminates the entire cooktop surface for the perfect sear or ideal reduction. Range hood settings, including temperature and fan speed, can be controlled via the SmartHQ™ app, with additional voice control options for fan speeds and lighting.
EASY INSTALLATION
This range hood is the perfect partner to your Fisher & Paykel cooktop. It can be either externally ducted or internally recirculated, making it perfect for apartments.
COMPLEMENTARY DESIGN (STAINLESS STEEL FINISH)
The stainless steel finish of this vent hood will complement any contemporary kitchen and is designed to match the rest of Fisher & Paykel kitchen appliance family.
Specifications
General
Series Name
Series 7
Blower Included
Yes
Airflow
400 CFM
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Wi-Fi
Yes
Dishwasher-Proof Filters
Yes
Technologies
• Smart Appliance
• Wi-Fi Enabled
• Wi-Fi Enabled
Ducting Information
• Ducted: Top extraction
• Recirculation: Optional - top extraction
• Air Outlet Size: 6"
• Recirculation: Optional - top extraction
• Air Outlet Size: 6"
Speeds
4 Speeds
Additional Information
• Maximum Speed Sound Rating: 9.5 sones
• Speed 1 Sound Rating: 1.3 sones
• Stainless Steel Filter Cover
• Auto-off/Run-on Timer
• Dimmable Lights
• Filter Cleaning Alert
• Light Type: LED
• Timer Function
• Filter Type: Mesh
• Number of Filters: 2
• Speed 1 Sound Rating: 1.3 sones
• Stainless Steel Filter Cover
• Auto-off/Run-on Timer
• Dimmable Lights
• Filter Cleaning Alert
• Light Type: LED
• Timer Function
• Filter Type: Mesh
• Number of Filters: 2
Electrical Information
Information
• Rated Current: 5.2 A
• Supply Frequency: 60 Hz
• Supply Voltage: 120 V
• Supply Frequency: 60 Hz
• Supply Voltage: 120 V
Accessories
Optional
• Chimney Extension: 791774
• Recirculation Carbon Filter: 793602
• Recirculation Diverter: 792580
• Recirculation Carbon Filter: 793602
• Recirculation Diverter: 792580
Dimensions
Class Width
30"
Width
29.76 inch(es) / 75.6 cm
Height
25 inch(es) / 63.5 cm
Depth
19.68 inch(es) / 50.0 cm
Documents
