Features
TURBOSTEAM™ TECHNOLOGY
LG TurboSteam™ technology to the rescue. Toss the shirt in the dryer, turn on TurboSteam™ and in just 10 minutes your shirt is back in tip-top shape. Also helps refresh fabrics and reduce wrinkles in half the time of other Steam settings.
SMARTDIAGNOSIS™
If you ever experience an issue with your Lg dryer, you have to worry. The SmartDiagnosis™ feature helps the service center diagnose problems over the phone, or with a simple app on your smart phone, helping you minimize costly, inconvenient service calls.
SMARTTHINQ® TECHNOLOGY
Expand the limits of your laundry room with the LG SmartThinQ® app. Select a cycle, start or stop the wash and get notifications about when your laundry will be done, all from your smartphone. It even works with the Google Assistant and Amazon Alexa, so you can manage your laundry with simple voice commands.
Specifications
General
Type
Vented
Power Source
Electric
Color
Black Stainless
Manufacturer Color
Black Stainless Steel
Tub Material
Stainless Steel
Capacity
Capacity
7.4 cu. ft.
Cycle Information
Number of Cycles
23
Dry Cycles
• Normal
• AI Dry
• Bedding
• Delicates
• Towels
• Quick Dry
• Timed Dry
• Antibacterial
• Perm.Press
• SteamFresh™
• Heavy Duty
• Air Dry
• Steam Sanitary™
• Super Dry
• Active Wear
• Denim -> Jeans
• Blanket Refresh
• Low Temp Dry
• Overnight Dry
• Easy Ironing
• Small Load
• Large Load Dry
• X Large Load Dry
• AI Dry
• Bedding
• Delicates
• Towels
• Quick Dry
• Timed Dry
• Antibacterial
• Perm.Press
• SteamFresh™
• Heavy Duty
• Air Dry
• Steam Sanitary™
• Super Dry
• Active Wear
• Denim -> Jeans
• Blanket Refresh
• Low Temp Dry
• Overnight Dry
• Easy Ironing
• Small Load
• Large Load Dry
• X Large Load Dry
Options
• Cycle Optimization
• Damp Dry Signal
• Wrinkle Care
• Control Lock
• Wi-Fi, Energy Saver
• TurboSteam™
• Reduce Static
• Remote Start
• Drum Light
• Signal
• Damp Dry Signal
• Wrinkle Care
• Control Lock
• Wi-Fi, Energy Saver
• TurboSteam™
• Reduce Static
• Remote Start
• Drum Light
• Signal
Features
Technologies
• Dial-A-Cycle™
• AI Sensor Dry™
• TurboSteam™
• LoDecibel™ Quiet Operation
• FlowSense™ Duct Clogging Indicator
• SmartDiagnosis™ (v3.0)
• Wi-Fi
• NeveRust™ Stainless Steel Drum
• AI Sensor Dry™
• TurboSteam™
• LoDecibel™ Quiet Operation
• FlowSense™ Duct Clogging Indicator
• SmartDiagnosis™ (v3.0)
• Wi-Fi
• NeveRust™ Stainless Steel Drum
Dryness Levels
• Very Dry
• More Dry
• Normal Dry
• Less Dry
• Damp Dry
• More Dry
• Normal Dry
• Less Dry
• Damp Dry
Temperature Settings
• High
• Med.High
• Medium
• Low
• Ultra Low
• Med.High
• Medium
• Low
• Ultra Low
Number of Temperature Settings
5
Wi-Fi
Yes
Steam Cycle
Yes
Control Lock
Yes
Light
Yes
Digital Display
Yes
Reversible Door
Yes
Sensor Dry
Yes
Stackable
Yes
Additional Information
• LCD Display
• Precise Temperature Control with Variable Heater
• 3 Minute Installation Check
• End of Cycle Signal
• Remaining Time Display/Status Indicator(s)
• Energy Monitoring
• Proactive Customer Care (PCC) Remote start and cycle monitor
• Precise Temperature Control with Variable Heater
• 3 Minute Installation Check
• End of Cycle Signal
• Remaining Time Display/Status Indicator(s)
• Energy Monitoring
• Proactive Customer Care (PCC) Remote start and cycle monitor
Electrical Information
Information
• 230 V
• 30 A
• 30 A
Certifications and Approvals
Energy Star Certified
Yes
Additional Information
CSA Listed
Accessories
Optional
• LP Conversion Kit 383EEL3002D
• Drying Rack 3750EL1001A
• Side Venting Kit 3911EZ9131X (replaces 383EEL9001B)
• Pedestal WDP6B
• Drying Rack 3750EL1001A
• Side Venting Kit 3911EZ9131X (replaces 383EEL9001B)
• Pedestal WDP6B
Dimensions
Class Width
26" - 27"
Width
27 inch(es) / 68.58 cm
Height
39 inch(es) / 99.06 cm
Depth
30.12 inch(es) / 76.51 cm
Weight
123.7 lb(s) / 56.11 kg
Additional Dimensions
Depth with Door Open: 51 3/8"
Shipping Dimensions
Width
29.62 inch(es) / 75.24 cm
Height
43.31 inch(es) / 110.01 cm
Depth
31.56 inch(es) / 80.16 cm
Weight
135.1 lb(s) / 61.28 kg
Warranty
Warranty
• Parts & Labor: 1 Year
• Drum: 3 Years
• Drum: 3 Years
UPC
UPC#
195174036976
