Features
BLUE LED RING
The blue LED light rises through the glass
top for an easy-to-use and beautiful design.
IR SENSOR
The Panasonic IR Sensor quickly and accurately detects only the pot's bottom temperature, and the control program rapidly raises it to the set temperature, then holds it there.
INFRARED-SENSOR
Next Generation sensor technology and an advanced control program optimize cooking temperature. The Panasonic Infrared-Sensor quickly and accurately detects only the pot’s bottom temperature and the control program rapidly raises it to the set temperature and then consistently holds it.
ENERGY SAVINGS
Maintaining a consistent set temperature reduces unnecessary power consumption. Panasonic’s next generation Infrared-Sensor efficiently controls power settings in response to changes in cooking conditions (eg. Ingredient temperature and the size of cookware) which eliminates unnecessary heating. As a result energy usage is minimized.
TEMPERATURE PRESETS ELIMINATE GUESSWORK
For Pan Frying
Choose a pre-set ranging from 140 to 230 degrees, in 20-degree steps. The Panasonic Infrared-Sensor uses powerful heating to rapidly reach the desired temperature, then maintains it to cook foods all the way through for delicious results every time.
For Deep Frying
Choose a pre-set ranging from 140 to 200 degrees, in 10-degree steps. Even if you simmer foods for a long time, or add ingredients midway, the Infrared-Sensor consistently maintains the precise set temperature for perfect results every time.
Specifications
General
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Front: 2 x (70 - 3,300 W)
• Rear: 2 x (70 - 1,800 W)
• Rear: 2 x (70 - 1,800 W)
Elements
Smoothtop
Surface Features
Black Glass Plate
Features
Technologies
Induction Technology
Control Lock
Yes
Digital Display
Yes
Additional Information
• Cooking Zones: LED Ring Blue
• Display: LED Blue
• 18 Power Levels
• Electrostatic Touch Panel
• Infra-Red Rays Sensor (Front 2 Zones)
• Thermo Sensor (4 Zones)
• Timer: 1 Min - 99 Min
• Main Switch: On/Off
• Power Cord Length: 1,200 Mm
• Deep-Fry: 7 Levels (140, 150, 160, 170, 180 190, 200ºC)
• Pan-Fry: 5 Levels (140, 160, 180, 200, 230ºC)
• Maximum Power: 7,200 W
• Display: LED Blue
• 18 Power Levels
• Electrostatic Touch Panel
• Infra-Red Rays Sensor (Front 2 Zones)
• Thermo Sensor (4 Zones)
• Timer: 1 Min - 99 Min
• Main Switch: On/Off
• Power Cord Length: 1,200 Mm
• Deep-Fry: 7 Levels (140, 150, 160, 170, 180 190, 200ºC)
• Pan-Fry: 5 Levels (140, 160, 180, 200, 230ºC)
• Maximum Power: 7,200 W
Electrical Information
Information
208/240 V AC, 60 Hz, Single phase
Dimensions
Class Width
30"
Width
30.43 inch(es) / 77.3 cm
Height
3.27 inch(es) / 8.3 cm
Depth
21.1 inch(es) / 53.6 cm
Weight
35.27 lb(s) / 16 kg
Additional Dimensions
Cooktop Opening: 727 x 490 mm
Shipping Dimensions
Width
35.43 inch(es) / 89.99 cm
Height
6.3 inch(es) / 16 cm
Depth
25.59 inch(es) / 65 cm
