Features
PULL-OUT SHELVES
Industry Exclusive adjustable, full-extension pull-out shelves (drawer models excluded)
CRISP WHITE AND COOL BLUE LED
Crisp White and Cool Blue LED lighting; easily switch back and forth with the flip of a switch.
DIGITAL TEMPERATURE CONTROL
Digital temperature control provides clear, accurate temperature readout.
STAINLESS STEEL INTERIORS
Sleek stainless steel interiors are not only beautiful to look at, but also provide a sanitary environment resistant to stains and odors.
Specifications
General
Series Name
• HH24RS
• Signature Series
• Signature Series
Refrigerator Type
Compact
Installation Type
Freestanding/Built-in
Door Hinge
Left
Color
Panel Ready
Manufacturer Color
• Solid panel ready door
• Custom panel required (sold separately)
• Custom panel required (sold separately)
Capacity
Total
3.1 cu. ft.
Refrigerator
3.1 cu. ft.
Refrigerator Features
Digital Display
Yes
Door Alarm
Yes
Frost Free
Yes
Interior Light
Yes
Additional Information
• 18" shallow depth for ultimate design flexibility in tight spaces
• Storage for up to 68 cans
• Commercial-grade all stainless steel interior
• Full-extension shelving provides faster and safer product access with no reaching in the back of the cabinet
• Shelves fully extend on vibration dampened stainless steel ball bearing glides
• Temperature Settings F°(C°): 33° (0.5°) - 48° (8.8°)
• Factory Set Point: 36° (2.2°)
• Lighting Type: LED (Selectable blue or white)
• Defrost Initiation: Automatic
• Defrost Type: Off cycle
• Audible door alarm warns user if door is held open
• Refrigerant: R600a (50g)
• Variable speed compressor minimizes sound
• Front vented
• Cord Plug Type: NEMA 3 Prong 5-15P
• Storage for up to 68 cans
• Commercial-grade all stainless steel interior
• Full-extension shelving provides faster and safer product access with no reaching in the back of the cabinet
• Shelves fully extend on vibration dampened stainless steel ball bearing glides
• Temperature Settings F°(C°): 33° (0.5°) - 48° (8.8°)
• Factory Set Point: 36° (2.2°)
• Lighting Type: LED (Selectable blue or white)
• Defrost Initiation: Automatic
• Defrost Type: Off cycle
• Audible door alarm warns user if door is held open
• Refrigerant: R600a (50g)
• Variable speed compressor minimizes sound
• Front vented
• Cord Plug Type: NEMA 3 Prong 5-15P
Electrical Information
Information
• Electrical Supply: 115 VAC/60 Hz/1 Ph
• Running Load Amps: 2.2 amps
• 259 kWh
• Running Load Amps: 2.2 amps
• 259 kWh
Certifications and Approvals
Energy Star Certified
Yes
ADA Compliant
Yes
Accessories
Optional
• Factory-installed lock: (L)
• Stacking Kit for HH24 models: 67992-L/R
• 6" Toe Kick and Riser: 67360
• Stacking Kit for HH24 models: 67992-L/R
• 6" Toe Kick and Riser: 67360
Dimensions
Class Width
23" to 28.9"
Class Height
30" - 35"
Width
23.87 inch(es) / 60.63 cm
Height (With Hinge)
32 inch(es) / 81.28 cm
Depth (Without Handles)
18 inch(es) / 45.72 cm
Additional Dimensions
• Opening dimensions: 24"W x 18"D x 32.25"H
• Cord length: 6'
• Cord length: 6'
Shipping Dimensions
Weight
184.99 lb(s) / 83.91 kg
Warranty
Warranty
6-year warranty
