Features
DIGITAL TEMPERATURE CONTROL
Digital temperature control provides clear, accurate temperature readout.

STAINLESS STEEL INTERIORS
Sleek stainless steel interiors are not only beautiful to look at, but also provide a sanitary environment resistant to stains and odors.

Additional Features
SIGNATURE SERIES DUAL-ZONE
Perlick’s patented Signature Series Dual-Zone models offer two independently-controlled temperature zones within a single 24" footprint to make the most out of your available space.
Specifications
General
Series Name
Signature
Refrigerator Type
Drawers
Installation Type
Freestanding
Door Hinge
Drawer
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Capacity
Total
5.0 cu. ft.
Refrigerator Features
Digital Display
Yes
Door Alarm
Yes
Frost Free
Yes
Interior Light
Yes
Additional Information
• Patented dual zone technology allows to store fresh and frozen foods at their appropriate temperatures
• Commercial-grade all stainless steel interior and exterior provide superior durability and easy cleaning
• 1000 BTU/hr capacity delivers industry's most energy-efficient cool down
• Heat rejection (at 75°F): 700 BTU/hr
• Variable speed compressor minimizes sound
• Smooth glide self-closing drawers offer high storage capacity
• Audible door alarm warns the user if the drawer is held open
• R600a Natural Refrigerant – maximum energy efficiency with zero global warming impact
• White LED task lighting illuminates cabinet when drawers are opened
• Temperature range F°(C°): -10° (-23.3°) - 10° (-12.2°)
• Factory set point: 0° (-17.8°)
• Cord length: 6'
• Cord plug type: NEMA 3 Prong 5-15P
• Defrost type: Hot gas
• Factory-installed lock
• Commercial-grade all stainless steel interior and exterior provide superior durability and easy cleaning
• 1000 BTU/hr capacity delivers industry's most energy-efficient cool down
• Heat rejection (at 75°F): 700 BTU/hr
• Variable speed compressor minimizes sound
• Smooth glide self-closing drawers offer high storage capacity
• Audible door alarm warns the user if the drawer is held open
• R600a Natural Refrigerant – maximum energy efficiency with zero global warming impact
• White LED task lighting illuminates cabinet when drawers are opened
• Temperature range F°(C°): -10° (-23.3°) - 10° (-12.2°)
• Factory set point: 0° (-17.8°)
• Cord length: 6'
• Cord plug type: NEMA 3 Prong 5-15P
• Defrost type: Hot gas
• Factory-installed lock
Electrical Information
Information
• 115 VAC
• 60 Hz
• 2.2 amps
• 1 Ph
• 418 kWh/yr
• 60 Hz
• 2.2 amps
• 1 Ph
• 418 kWh/yr
Accessories
Optional
• Stacking Kit for HP24/HC24/HA24 models: RS-SK-24L/R
• Caster Kit for HP24/HC24/HA24 models: 66736
• Drawer Pan Tray (3 SS pans with covers): RK24DP
• Caster Kit for HP24/HC24/HA24 models: 66736
• Drawer Pan Tray (3 SS pans with covers): RK24DP
Dimensions
Class Width
23" to 28.9"
Class Height
30" - 35"
Width
23.88 inch(es) / 60.66 cm
Height (With Hinge)
34.24 inch(es) / 86.96 cm
Depth (Without Handles)
24 inch(es) / 60.96 cm
Additional Dimensions
Opening dimensions: 24"W x 24.87"D x 34.5"H
Shipping Dimensions
Weight
144.01 lb(s) / 65.32 kg
Warranty
Warranty
6-year warranty
