Features
STAINLESS-STEEL BALL-BEARING
Stainless-steel ball-bearing glides provide smooth
movement of shelves.
STAINLESS STEEL INTERIORS
Sleek stainless steel interiors are not only beautiful to look at, but also provide a sanitary environment resistant to stains and odors.
DIGITAL CONTROLLER WITH AUDIBLE DOOR ALARM
Digital controller with audible door alarm provides precision temperature control and readout.
Additional Features
RAPIDCOOL
Front-vented, RAPIDcool forced-air refrigeration system.
Specifications
General
Series Name
• HA24FB
• ADA-Compliant Series
• ADA-Compliant Series
Type
Compact
Style
Undercounter Built-in
Color
Panel Ready
Manufacturer Color
• Solid panel ready door
• Custom panel required (sold separately)
• Custom panel required (sold separately)
Total Capacity
4.8 cu. ft.
Size Range
23 cu.ft. - 24 cu.ft.
Door Hinge
Left
Features
Technologies
Front-vented, RAPIDcool™ forced air refrigeration system
Digital Temperature Display
Yes
Lighting
Yes
Alarm
Yes
Additional Information
• Variable speed compressor minimizes sound
• Commercial-grade all stainless steel interior provides superior durability and easy cleaning
• Black vinyl exterior for built-in applications
• Full-extension shelving provides faster and safer product access with no reaching in the back of the cabinet
• Shelves fully extend on vibration dampened stainless steel ball-bearing glides
• Audible door alarm warns the user if the door is held open
• White LED task lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero global warming potential
• Cord plug type: NEMA 3 Prong 5-15P
• Temperature settings F°(C°): -10° (-23.3°) - 10° (12.2°)
• Hot gas defrost initiation
• Factory-installed lock
• Commercial-grade all stainless steel interior provides superior durability and easy cleaning
• Black vinyl exterior for built-in applications
• Full-extension shelving provides faster and safer product access with no reaching in the back of the cabinet
• Shelves fully extend on vibration dampened stainless steel ball-bearing glides
• Audible door alarm warns the user if the door is held open
• White LED task lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero global warming potential
• Cord plug type: NEMA 3 Prong 5-15P
• Temperature settings F°(C°): -10° (-23.3°) - 10° (12.2°)
• Hot gas defrost initiation
• Factory-installed lock
Electrical Information
Information
• 115 VAC
• 60 Hz
• 2.2 amps
• 1 Ph
• 437 kWh/yr V
• 60 Hz
• 2.2 amps
• 1 Ph
• 437 kWh/yr V
Certifications and Approvals
Additional Certifications and Approvals
• ADA-height compliant
• cULus
• cULus
Accessories
Optional
• 6" Toe Kick Kit (includes riser) for HA24 models: 67164
• Caster Kit for HP24/HC24/HA24 models: 66736
• Caster Kit for HP24/HC24/HA24 models: 66736
Dimensions
Width
23.87 inch(es) / 60.63 cm
Height (With Hinge)
32 inch(es) / 81.28 cm
Depth (Without Handles)
24 inch(es) / 60.96 cm
Additional Dimensions
• Opening dimensions: 24"W x 24.87"D x 32.25"H
• Cord length: 6'
• Cord length: 6'
Shipping Dimensions
Weight
181 lb(s) / 82.1 kg
Warranty
Warranty
6-year warranty
