Features
STAINLESS STEEL INTERIORS
Sleek stainless steel interiors are not only beautiful to look at, but also provide a sanitary environment resistant to stains and odors.
DIGITAL CONTROLLER WITH AUDIBLE DOOR ALARM
Digital controller with audible door alarm provides precision temperature control and readout.
Specifications
General
Series Name
Signature
Type
Drawers
Style
Undercounter Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Total Capacity
5.0 cu. ft.
Size Range
23 cu.ft. - 24 cu.ft.
Features
Defrost System / Frost Free
Yes
Digital Temperature Display
Yes
Lighting
Yes
Alarm
Yes
Additional Information
• 1000 BTU/hr capacity delivers energy efficient cool down
• Heat rejection (at 75°F): 700 BTU/hr
• Variable speed compressor minimizes sound
• Commercial-grade all stainless steel interior and exterior provide superior durability and easy cleaning
• Audible door alarm warns the user if the drawer is held open
• 2 smooth glide self-closing drawers offer high storage capacity
• White LED task lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero global warming potential
• Cord plug type: NEMA 3 Prong 5-15P
• Cord length: 6'
• Temperature settings F°(C°): -10° (-23.3°) - 10° (12.2°)
• Factory set point: 0° (-17.8°)
• Hot gas defrost initiation
• Factory-installed lock
• Heat rejection (at 75°F): 700 BTU/hr
• Variable speed compressor minimizes sound
• Commercial-grade all stainless steel interior and exterior provide superior durability and easy cleaning
• Audible door alarm warns the user if the drawer is held open
• 2 smooth glide self-closing drawers offer high storage capacity
• White LED task lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero global warming potential
• Cord plug type: NEMA 3 Prong 5-15P
• Cord length: 6'
• Temperature settings F°(C°): -10° (-23.3°) - 10° (12.2°)
• Factory set point: 0° (-17.8°)
• Hot gas defrost initiation
• Factory-installed lock
Electrical Information
Information
• 115 VAC
• 60 Hz
• 2.2 amps
• 1 Ph
• 440 kWh/yr V
• 60 Hz
• 2.2 amps
• 1 Ph
• 440 kWh/yr V
Accessories
Optional
• Caster Kit for HP24/HC24/HA24 models: 66736
• 24" Stainless steel drawer dividers: 67969
• 24" Drawer prep station tray: RK24DP
• 24" Stainless steel drawer dividers: 67969
• 24" Drawer prep station tray: RK24DP
Dimensions
Width
23.87 inch(es) / 60.63 cm
Height (With Hinge)
34.25 inch(es) / 87 cm
Depth (Without Handles)
24 inch(es) / 60.96 cm
Additional Dimensions
Opening dimensions: 24"W x 24.87"D x 34.5"H
Shipping Dimensions
Weight
144.01 lb(s) / 65.32 kg
Warranty
Warranty
6-year warranty
