Features
STAINLESS-STEEL BALL-BEARING
Stainless-steel ball-bearing glides provide smooth
movement of shelves.
STAINLESS STEEL INTERIORS
Sleek stainless steel interiors are not only beautiful to look at, but also provide a sanitary environment resistant to stains and odors.
DIGITAL CONTROLLER WITH AUDIBLE DOOR ALARM
Digital controller with audible door alarm provides precision temperature control and readout.
Specifications
General
Series Name
Signature
Type
Compact
Style
Undercounter Freestanding
Color
Panel Ready
Manufacturer Color
• Solid panel ready door
• Custom panel required (sold separately)
• Custom panel required (sold separately)
Total Capacity
5.2 cu. ft.
Size Range
23 cu.ft. - 24 cu.ft.
Door Hinge
Right
Features
Defrost System / Frost Free
Yes
Digital Temperature Display
Yes
Lighting
Yes
Alarm
Yes
Additional Information
• 1000 BTU/hr capacity delivers energy efficient cool down
• Heat rejection (at 75°F): 700 BTU/hr
• Variable speed compressor minimizes sound
• Commercial-grade all stainless steel interior and exterior provide superior durability and easy cleaning
• Full-extension shelving provides faster and safer product access with no reaching in the back of the cabinet
• Shelves fully extend on vibration dampened stainless steel ball-bearing glides
• Audible door alarm warns the user if the door is held open
• White LED task lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero global warming potential
• Cord plug type: NEMA 3 Prong 5-15P
• Cord length: 6'
• Temperature settings F°(C°): -10° (-23.3°) - 10° (12.2°)
• Factory set point: 36° (2.2°)
• Hot gas defrost initiation
• Factory-installed lock
• Heat rejection (at 75°F): 700 BTU/hr
• Variable speed compressor minimizes sound
• Commercial-grade all stainless steel interior and exterior provide superior durability and easy cleaning
• Full-extension shelving provides faster and safer product access with no reaching in the back of the cabinet
• Shelves fully extend on vibration dampened stainless steel ball-bearing glides
• Audible door alarm warns the user if the door is held open
• White LED task lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero global warming potential
• Cord plug type: NEMA 3 Prong 5-15P
• Cord length: 6'
• Temperature settings F°(C°): -10° (-23.3°) - 10° (12.2°)
• Factory set point: 36° (2.2°)
• Hot gas defrost initiation
• Factory-installed lock
Electrical Information
Information
• 115 VAC
• 60 Hz
• 2.2 amps
• 1 Ph
• 445 kWh/yr V
• 60 Hz
• 2.2 amps
• 1 Ph
• 445 kWh/yr V
Accessories
Optional
• Stacking Kit for HP24/HC24/HA24 models: 67991-L/R
• Caster Kit for HP24/HC24/HA24 models: 66736
• Martini rack: RS-24-24M
• Caster Kit for HP24/HC24/HA24 models: 66736
• Martini rack: RS-24-24M
Dimensions
Width
23.87 inch(es) / 60.63 cm
Height (With Hinge)
34.25 inch(es) / 87 cm
Depth (Without Handles)
24 inch(es) / 60.96 cm
Additional Dimensions
Opening dimensions: 24"W x 24.87"D x 34.5"H
Shipping Dimensions
Weight
144.01 lb(s) / 65.32 kg
Warranty
Warranty
6-year warranty
