Specifications
General
Series Name
Signature Series
Refrigerator Type
Compact
Installation Type
Freestanding/Built-in
Door Hinge
Right
Color
Panel Ready
Manufacturer Color
• Solid Panel Ready Door
• Requires custom panel (sold separately)
• Requires custom panel (sold separately)
Capacity
Total
5.2 cu. ft.
Refrigerator
5.2 cu. ft.
Refrigerator Features
Door Alarm
Yes
Frost Free
Yes
Interior Light
Yes
Additional Information
• Commercial-grade all stainless steel interior and exterior provide superior durability and easy cleaning
• 1000 BTU/hr capacity delivers industry's most energy efficient cool down
• Variable speed compressor minimizes sound
• Full-extension shelving provides faster and safer product access with no reaching in the back of the cabinet
• Shelves fully extend on vibration dampened stainless steel ball-bearing glides
• Audible door alarm warns user if door is held open
• Selectable blue or white LED lighting
• R600a Natural Refrigerant
• Storage for up to 144 cans
• Temperature Settings F°(C°): 33° (0.5°) - 48° (8.8°)
• Factory Set Point: 36° (2.2°)
• Cord Plug Type: NEMA 3 Prong 5-15P
• Front Vented
• 1000 BTU/hr capacity delivers industry's most energy efficient cool down
• Variable speed compressor minimizes sound
• Full-extension shelving provides faster and safer product access with no reaching in the back of the cabinet
• Shelves fully extend on vibration dampened stainless steel ball-bearing glides
• Audible door alarm warns user if door is held open
• Selectable blue or white LED lighting
• R600a Natural Refrigerant
• Storage for up to 144 cans
• Temperature Settings F°(C°): 33° (0.5°) - 48° (8.8°)
• Factory Set Point: 36° (2.2°)
• Cord Plug Type: NEMA 3 Prong 5-15P
• Front Vented
Electrical Information
Information
• Electrical Supply: 115 VAC/60 Hz/1 Ph
• Running Load Amps: 2.2 amps
• Running Load Amps: 2.2 amps
Certifications and Approvals
Energy Star Certified
Yes
Sabbath Mode
Yes
Accessories
Optional
• 67991-L/R: Stacking Kit for HP24/HC24/HA24 models
• 66736: Caster Kit for HP24/HC24/HA24 models
• RK24DP: Drawer Pan Tray (3 SS pans with covers)
• 66736: Caster Kit for HP24/HC24/HA24 models
• RK24DP: Drawer Pan Tray (3 SS pans with covers)
Dimensions
Class Width
23" to 28.9"
Class Height
30" - 35"
Width
23.87 inch(es) / 60.64 cm
Height (With Hinge)
34.25 inch(es) / 87 cm
Depth (Without Handles)
24 inch(es) / 60.96 cm
Additional Dimensions
Cord Length: 6'
Shipping Dimensions
Weight
191.01 lb(s) / 86.64 kg
Warranty
Warranty
3-Year Warranty plus additional 3 years on sealed system
