Features
ADJUSTABLE CRISP WHITE AND COOL BLUE LED LIGHTING
Perlick Signature Series models feature both white and blue LED lighting (drawer models excluded). With just the flip of the switch, you can transform the lighting in your cabinet from the fresh glow of crisp white to oh-so-very cool blue.

STAINLESS STEEL INTERIORS
Perlick’s entire line of undercounter refrigeration boasts stainless steel interiors, providing a sanitary, easy to clean surface that won’t harbor odors and bacteria like plastic interiors.

DIGITAL CONTROLLER WITH AUDIBLE DOOR ALARM
Digital controller with audible door alarm provides precision temperature control and readout.

ROBUST, FORCED-AIR REFRIGERATION
Product chills in 30 minutes thanks to Perlick’s front-vented, RAPIDcool™ forced-air refrigeration system. Cold air circulates throughout the cabinet to maintain consistent temperature anywhere in the cabinet. Because of this, product is perfectly chilled, eliminating ice build up in the back of the cabinet which often happens with units cooled by a cold plate.

Specifications
General
Series Name
• HA24BB
• ADA-Compliant Series
• ADA-Compliant Series
Type
Beverage Center
Installation
Built-In
Size
Compact
Color
Panel Ready
Manufacturer Color
• Panel ready glass door
• Custom panel required (sold separately)
• Custom panel required (sold separately)
Cabinet Color
Black
Temperature Zones
1
Temperature Settings
• Temperature range: 33° - 48°F (0.5° - 8.8°C)
• Factory set point: 36° (2.2°)
• Factory set point: 36° (2.2°)
Hinge Side
Left
Capacity
Total Capacity
4.8 cu. ft.
Cans
62
Bottles
16
Features
Technologies
Perlick's RAPIDcool forced-air refrigeration system
Digital Temperature Display
Yes
Glass Door
Yes
Interior Light
Yes
Additional Information
• Commercial-grade all stainless steel interior provides superior durability and easy cleaning
• Variable speed compressor minimizes sound
• Wine and refrigerator shelves fully extend on vibration dampened, stainless steel ball-bearing glides
• Stainless steel wine shelves will not absorb odors over time
• Audible door alarm warns the user if the door is held open
• Selectable blue or white LED lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero ozone depletion potential
• Cord plug type: NEMA 3 Prong 5-15P
• Automatic defrost initiation
• Variable speed compressor minimizes sound
• Wine and refrigerator shelves fully extend on vibration dampened, stainless steel ball-bearing glides
• Stainless steel wine shelves will not absorb odors over time
• Audible door alarm warns the user if the door is held open
• Selectable blue or white LED lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero ozone depletion potential
• Cord plug type: NEMA 3 Prong 5-15P
• Automatic defrost initiation
Electrical Information
Information
• 115 VAC
• 60 Hz
• 2.2 amps
• 1 Ph
• 272 kWh/yr
• 60 Hz
• 2.2 amps
• 1 Ph
• 272 kWh/yr
Certifications and Approvals
Energy Star Certified
Yes
Information
• ADA-height compliant
• cULus
• cULus
Accessories
Included
Factory-installed lock
Optional
• 6" Toe Kick Kit (includes riser) for HA24 models: 67164
• Caster Kit for HP24/HC24/HA24 models: 66736
• Divider Shelf for HP24/HC24/HA24 models: RS-24-24D
• Caster Kit for HP24/HC24/HA24 models: 66736
• Divider Shelf for HP24/HC24/HA24 models: RS-24-24D
Dimensions
Class Width
24"
Width
23.88 inch(es) / 60.66 cm
Height
32 inch(es) / 81.28 cm
Depth
24 inch(es) / 60.96 cm
Additional Dimensions
• Opening dimensions: 24"W x 24.87"D x 32.5"H
• Cord length: 6'
• Cord length: 6'
Shipping Dimensions
Weight
181 lb(s) / 82.1 kg
Warranty
Warranty
6-year warranty
