Features
PERLICK’S FRONT-VENTED, RAPIDCOOL
Perlick’s front-vented, rapidcool™ forced-air refrigeration
System cools product quickly by continuously circulating cold
Air throughout the cabinet – also providing consistent temperature
And eliminating cold spots

CRISP WHITE AND COOL BLUE LED
Crisp White and Cool Blue LED lighting; easily switch back and forth with the flip of a switch.

STAINLESS STEEL INTERIORS
Sleek stainless steel interiors are not only beautiful to look at, but also provide a sanitary environment resistant to stains and odors.

DIGITAL TEMPERATURE CONTROL
Digital temperature control provides clear, accurate temperature readout.

Specifications
General
Series Name
• HA24RB
• ADA-Compliant Series
• ADA-Compliant Series
Refrigerator Type
Compact
Installation Type
Built-In
Door Hinge
Left
Color
Panel Ready
Manufacturer Color
• Solid panel ready door
• Custom panel required (sold separately)
• Custom panel required (sold separately)
Capacity
Total
4.8 cu. ft.
Refrigerator Features
Technologies
RAPIDcool forced-air refrigeration system
Digital Display
Yes
Door Alarm
Yes
Frost Free
Yes
Interior Light
Yes
Additional Information
• Audible door alarm warns user if door is held open
• Selectable blue or white LED lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero ozone depletion potential
• Storage for up to 108 cans
• 800 BTU/hr capacity delivers commercial-grade cooling performance
• Variable speed compressor minimizes sound
• Commercial-grade all stainless steel interior provides superior durability and easy cleaning
• Black vinyl exterior for built-in applications
• Full extension shelving provides faster and safer product access with no reaching in the back of the cabinet
• Shelves fully extend on vibration dampened stainless steel ball-bearing glides
• Cord Plug Type: NEMA 3 Prong 5-15P
• Expansion Device: Capillary Tube
• Temperature Settings F°(C°): 33° (0.5°) - 48° (8.8°)
• Factory Set Point 36° (2.2°)
• Front Vented
• Selectable blue or white LED lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero ozone depletion potential
• Storage for up to 108 cans
• 800 BTU/hr capacity delivers commercial-grade cooling performance
• Variable speed compressor minimizes sound
• Commercial-grade all stainless steel interior provides superior durability and easy cleaning
• Black vinyl exterior for built-in applications
• Full extension shelving provides faster and safer product access with no reaching in the back of the cabinet
• Shelves fully extend on vibration dampened stainless steel ball-bearing glides
• Cord Plug Type: NEMA 3 Prong 5-15P
• Expansion Device: Capillary Tube
• Temperature Settings F°(C°): 33° (0.5°) - 48° (8.8°)
• Factory Set Point 36° (2.2°)
• Front Vented
Ice and Water
Ice System
None
Water System
None
Electrical Information
Information
• Electrical Supply: 115 VAC/60 Hz/1 Ph
• Running Load Amps: 2.2 amps
• Running Load Amps: 2.2 amps
Certifications and Approvals
Energy Star Certified
Yes
ADA Compliant
Yes
Accessories
Included
Factory-Installed Door Lock
Optional
• 67164: 6" Toe Kick Kit (includes riser) for HA24 models
• 66736: Caster Kit for HP24/HC24/HA24 models
• RS-24-24D: Divider Shelf for HP24/HC24/HA24 models
• 66736: Caster Kit for HP24/HC24/HA24 models
• RS-24-24D: Divider Shelf for HP24/HC24/HA24 models
Dimensions
Class Width
23" to 28.9"
Class Height
30" - 35"
Width
23.87 inch(es) / 60.64 cm
Height (With Hinge)
32 inch(es) / 81.28 cm
Depth (Without Handles)
24 inch(es) / 60.96 cm
Additional Dimensions
• Opening dimensions: 24"W x 24.87"D x 32.25"H
• Cord length: 6'
• Cord length: 6'
Shipping Dimensions
Weight
181 lb(s) / 82.10 kg
Warranty
Warranty
Full 6 year warranty for owner ease of mind
