Features
RAPIDCOOL
Front-vented, RAPIDcool forced-air refrigeration system

STAINLESS STEEL INTERIOR
Commercial-grade stainless steel interior and exterior.

SOFT-COAT GLIDE OUT SHELVING
Eliminates vibration which can disturb sediment and alter the flavor and quality of wine.

CRISP WHITE AND COOL BLUE LED LIGHTING
Perlick is excited to announce that all door model 15-, 24-, 48-inch Signature Series models now feature both white and blue LED lighting (drawer models excluded). With just the flip of the switch, you can transform the lighting in your cabinet from the fresh glow of crisp white to oh-so-very cool blue.

DIGITAL CONTROLLER WITH AUDIBLE DOOR ALARM
Digital controller with audible door alarm provides precision temperature control and readout.

Specifications
General
Series Name
• HA24WB
• ADA-Compliant Series
• ADA-Compliant Series
Capacity
4.8 Cu. Ft.
Bottles
32
Temperature Zones
1
Temperature Settings
• Temperature Settings F°(C°): 45° (7.2°) - 65° (18.3°)
• Factory Set Point: 36° (2.2°)
• Factory Set Point: 36° (2.2°)
Installation
Built-In
Type
Cooler
Size
Compact
Color
Panel Ready
Manufacturer Color
• Panel ready glass door
• Custom panel required (sold separately)
• Custom panel required (sold separately)
Cabinet Color
Black
Hinge
Left
Features
Technologies
RAPIDcool forced-air refrigeration system
Digital Temperature Display
Yes
Glass Door
Yes
Interior Light
Yes
Additional Information
• Variable speed compressor minimizes sound
• Commercial-grade all stainless steel interior provides superior durability and easy cleaning
• Black vinyl exterior for built-in applications
• Wine shelves fully extend on vibration dampened, stainless steel ball-bearing glides
• Stainless steel wine shelves will not absorb odors over time
• Audible door alarm warns the user if the door is held open
• Selectable blue or white LED lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero ozone depletion potential
• Front Vented
• Cord Plug Type: NEMA 3 Prong 5-15P
• Commercial-grade all stainless steel interior provides superior durability and easy cleaning
• Black vinyl exterior for built-in applications
• Wine shelves fully extend on vibration dampened, stainless steel ball-bearing glides
• Stainless steel wine shelves will not absorb odors over time
• Audible door alarm warns the user if the door is held open
• Selectable blue or white LED lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero ozone depletion potential
• Front Vented
• Cord Plug Type: NEMA 3 Prong 5-15P
Electrical Information
Information
• Electrical Supply: 115 VAC/60 Hz/1 Ph
• Running Load Amps: 2.2 amps
• Running Load Amps: 2.2 amps
Certifications and Approvals
Energy Star Certified
No
Sabbath/Star-K
No
Information
ADA-Compliant
Accessories
Optional
• (L): Factory-installed lock
• 67164: 6" Toe Kick Kit (includes riser) for HA24 models
• 66736: Caster Kit for HP24/HC24/HA24 models
• 67164: 6" Toe Kick Kit (includes riser) for HA24 models
• 66736: Caster Kit for HP24/HC24/HA24 models
Dimensions
Width
23.87 inch(es) / 60.63 cm
Height
32 inch(es) / 81.28 cm
Depth (Without Handle)
24 inch(es) / 60.96 cm
Additional Dimensions
• Opening dimensions: 24"W x 24.87"D x 32.5"H
• Cord length: 6'
• Cord length: 6'
Shipping Dimensions
Weight
181 lb(s) / 82.1 kg
Warranty
Warranty
6-year warranty
