Features
CRISP WHITE AND COOL BLUE LED LIGHTING
Perlick is excited to announce that all door model 15-, 24-, 48-inch Signature Series models now feature both white and blue LED lighting (drawer models excluded). With just the flip of the switch, you can transform the lighting in your cabinet from the fresh glow of crisp white to oh-so-very cool blue.
DIGITAL CONTROLLER WITH AUDIBLE DOOR ALARM
Digital controller with audible door alarm provides precision temperature control and readout.
STAINLESS STEEL INTERIOR
Commercial-grade stainless steel interior and exterior.
RAPIDCOOL
Front-vented, RAPIDcool forced-air refrigeration system
Specifications
General
Series Name
• HC24WB
• C-Series
• C-Series
Capacity
5.2 Cu. Ft.
Bottles
45
Number of Racks
5
Temperature Zones
1
Temperature Settings
• Temperature Settings F°(C°): 45° (7.2°) - 65° (18.3°)
• Factory Set Point 36°F (2.2°C)
• Factory Set Point 36°F (2.2°C)
Installation
Built-In
Type
Cooler
Size
Compact
Color
Panel Ready
Manufacturer Color
• Panel ready glass door
• Custom panel required (sold separately)
• Custom panel required (sold separately)
Cabinet Color
Black
Hinge
Left
Features
Technologies
Perlick's RAPIDcool Forced-Air Refrigeration System
Digital Temperature Display
Yes
Glass Door
Yes
Interior Light
Yes
Additional Information
• Commercial-grade all stainless steel interior provides superior durability and easy cleaning
• Black vinyl exterior for built-in applications
• Variable speed compressor minimizes sound
• Wine shelves fully extend on vibration dampened
• Stainless steel ball-bearing glides
• Stainless steel wine shelves will not absorb odors over time
• Audible door alarm warns user if door is held open
• Selectable blue or white LED lighting
• Defrost Initiation: Automatic
• Defrost Type: Off-cycle
• Thermostat: Digital
• Lighting Type: LED
• Refrigerant: R600a (50g)
• Expansion Device: Capillary Tube
• Heat Rejection (at 75°F): 450 BTU/hr
• Pull Down Capacity: 800 BTU/hr
• Front Vented
• Factory-installed lock
• Black vinyl exterior for built-in applications
• Variable speed compressor minimizes sound
• Wine shelves fully extend on vibration dampened
• Stainless steel ball-bearing glides
• Stainless steel wine shelves will not absorb odors over time
• Audible door alarm warns user if door is held open
• Selectable blue or white LED lighting
• Defrost Initiation: Automatic
• Defrost Type: Off-cycle
• Thermostat: Digital
• Lighting Type: LED
• Refrigerant: R600a (50g)
• Expansion Device: Capillary Tube
• Heat Rejection (at 75°F): 450 BTU/hr
• Pull Down Capacity: 800 BTU/hr
• Front Vented
• Factory-installed lock
Electrical Information
Information
• Electrical Supply: 115 VAC/60 Hz/1 Ph
• Running Load Amps: 2.2 amps
• Cord Plug Type: NEMA 3 Prong 5-15P
• Running Load Amps: 2.2 amps
• Cord Plug Type: NEMA 3 Prong 5-15P
Certifications and Approvals
Information
cULus listed
Accessories
Optional
• Caster Kit for HP24/HC24/HA24 models: 66736
• Wood Faces for Wine Shelf (7/pk): 67115-24
• Wood Faces for Wine Shelf (7/pk): 67115-24
Dimensions
Width
23.87 inch(es) / 60.64 cm
Height
34.25 inch(es) / 87 cm
Depth (Without Handle)
24 inch(es) / 60.96 cm
Additional Dimensions
• Opening dimensions: 24"W x 24.88"D x 34.5"H
• Cord length: 6'
• Cord length: 6'
Shipping Dimensions
Weight
195 lb(s) / 88.45 kg
Warranty
Warranty
Full 6-year warranty for owner ease of mind
