Specifications
General
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Electric
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Left Rear Element Watts: 1800W
• Left Front Element Watts: 1200W
• Right Rear Element Watts: 1800W
• Right Front Element Watts: 1200W
• Left Front Element Watts: 1200W
• Right Rear Element Watts: 1800W
• Right Front Element Watts: 1200W
Burner/Element Size
• Dimensions of Left Rear Element: 8" (203 mm)
• Dimensions of Left Front Element: 6" (152 mm)
• Dimensions of Right Rear Element: 8" (203 mm)
• Dimensions of Right Front Element: 6" (152 mm)
• Dimensions of Left Front Element: 6" (152 mm)
• Dimensions of Right Rear Element: 8" (203 mm)
• Dimensions of Right Front Element: 6" (152 mm)
Elements
Smoothtop
Surface Features
Black Ceramic Glass Surface
Features
Control Lock
Yes
Digital Display
Yes
Additional Information
• Black Glass with Stainless Steel Side Edges & Beveled Front/Back
• 4 Hi-Lite Zones with 9 Power Levels
• Touch Control with Digital Display
• Digital Timer – up to 99 mins
• Quick Heating Ribbon Elements
• Pause Function
• Residual Heat Indicator
• Automatic Safety Shut Off
• Child Safety Lock
• 3" Deep for Easy Installation
• 4 Hi-Lite Zones with 9 Power Levels
• Touch Control with Digital Display
• Digital Timer – up to 99 mins
• Quick Heating Ribbon Elements
• Pause Function
• Residual Heat Indicator
• Automatic Safety Shut Off
• Child Safety Lock
• 3" Deep for Easy Installation
Electrical Information
Information
• Electrical Supply: 208V / 30Amp / 60Hz
• Amp Load: 240V / 40Amp / 60Hz
• Electrical Cable Hardwired: 51" (1300 mm)
• Amp Load: 240V / 40Amp / 60Hz
• Electrical Cable Hardwired: 51" (1300 mm)
Dimensions
Class Width
24"
Width
23.23 inch(es) / 59.0 cm
Height
3.15 inch(es) / 8.0 cm
Depth
20.47 inch(es) / 52.0 cm
Additional Dimensions
Cut Out Dimensions W / D (In/mm): 22 1/16" / 19 5/16" (560 mm / 490 mm)
