Features
TOUCH CONTROLS
STOP + GO FUNCTION
CHILD SAFETY LOCK
RESIDUAL HEAT INDICATOR
ADJUSTABLE TIME OF MAXIMUM 99 MINUTES
Specifications
General
Color
Black
Manufacturer Color
Black on Black
Fuel Type
Electric
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Single Zone: 1200 Watts;
• Double Zone: 1700 Watts;
• Single Zone: 2300 Watts
• Double Zone: 1700 Watts;
• Single Zone: 2300 Watts
Burner/Element Size
• 2 x 16cm Single Zone;
• 1 x 19cm Double Zone;
• 1 x 22cm Single Zone
• 1 x 19cm Double Zone;
• 1 x 22cm Single Zone
Elements
Smoothtop
Surface Features
ceramic
Features
Clock
No
Control Lock
Yes
Downdraft Ventilation
No
Additional Information
• 30" (76cm) induction cooktop;
• Stainless steel trim on sides, beveled glass on front and back edges;
• Touch Controls;
• 4 Electrical zones;
• LED display indicating power level;
• Adjustable time – max 99 minutes;
• Stop + Go function;
• Child safety lock;
• Residual heat indicator;
• 2" deep for easy installation.
• Stainless steel trim on sides, beveled glass on front and back edges;
• Touch Controls;
• 4 Electrical zones;
• LED display indicating power level;
• Adjustable time – max 99 minutes;
• Stop + Go function;
• Child safety lock;
• Residual heat indicator;
• 2" deep for easy installation.
Electrical Information
Information
208/240
Certifications and Approvals
Sabbath Mode
No
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
1.56 inch(es) / 3.96 cm
Depth
20.56 inch(es) / 52.22 cm
Additional Dimensions
Cut-out dimensions; • D: 19 13/16";
• W: 29 13/16"
Cooktop dimensions; • D: 20 9/16"
• W: 30 3/4"
• W: 29 13/16"
Cooktop dimensions; • D: 20 9/16"
• W: 30 3/4"
Warranty
Warranty
Porter&Charles products are designed and built to the highest standards.
Each appliance is covered by a comprehensive 2 year parts and labour warranty.
