Features
V-CONDENSE SYSTEM
The V-Condense system collects the condensation that forms on the filters, channeling it into the fixed collector integrated into the hood, thereby preventing dripping onto the hob and ensuring maximum operating efficiency.
Specifications
General
Series Name
Classic
Blower Included
Yes
Airflow
599 CFM
Style
Standard
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Under-Cabinet
Features
Speeds
Speed level 1:
• Extraction rate: 213 CFM
• Noise level: 54 dBA
• Power: 156 W
Speed 2:
• Extraction rate: 325.5 CFM
• Noise level: 63 dBA
• Power: 203 W
Speed 3:
• Extraction rate: 454 CFM
• Noise level: 70 dBA
• Power: 262 W
Intensive speed:
• Extraction rate: 590.5 CFM
• Noise level: 76 dBA
• Power: 353 W
• Extraction rate: 213 CFM
• Noise level: 54 dBA
• Power: 156 W
Speed 2:
• Extraction rate: 325.5 CFM
• Noise level: 63 dBA
• Power: 203 W
Speed 3:
• Extraction rate: 454 CFM
• Noise level: 70 dBA
• Power: 262 W
Intensive speed:
• Extraction rate: 590.5 CFM
• Noise level: 76 dBA
• Power: 353 W
Additional Information
• Design: Canopy pro-style
• Finishing: Satin
• Material: Stainless steel
• Stainless steel type: Brushed
• 24h air replacement function: Yes
• Auto-vent 2.0: Yes
• Extraction: Vented
• Electronic control: Yes
• No. of lights: 2
• Lighting: LED
• Light power: 1.3 W
• Dimmable light: Yes
• Light color temperature scale (K): 3000 K
• Motor power: 350 W
• No. of filters: 2
• Anti-grease filters: Stainless steel
• Filter replacement indicator: Yes
• Minimum distance from gas cooktop: 750"
• Minimum distance from electric cooktop: 650"
• Vent outlet: 5 7/8"
• Non-return valve: Yes
• Control setting: Touch controls
• Finishing: Satin
• Material: Stainless steel
• Stainless steel type: Brushed
• 24h air replacement function: Yes
• Auto-vent 2.0: Yes
• Extraction: Vented
• Electronic control: Yes
• No. of lights: 2
• Lighting: LED
• Light power: 1.3 W
• Dimmable light: Yes
• Light color temperature scale (K): 3000 K
• Motor power: 350 W
• No. of filters: 2
• Anti-grease filters: Stainless steel
• Filter replacement indicator: Yes
• Minimum distance from gas cooktop: 750"
• Minimum distance from electric cooktop: 650"
• Vent outlet: 5 7/8"
• Non-return valve: Yes
• Control setting: Touch controls
Electrical Information
Information
• Electrical connection rating: 353 W
• Voltage: 120 V
• Frequency (Hz): 60 Hz
• Power supply cable length: 1000"
• Voltage: 120 V
• Frequency (Hz): 60 Hz
• Power supply cable length: 1000"
Dimensions
Class Width
24"
Width
23.88 inch(es) / 60.66 cm
Height
13.88 inch(es) / 35.26 cm
Depth
19.31 inch(es) / 49.05 cm
Weight
22 lb(s) / 9.98 kg
Shipping Dimensions
Width
13.75 inch(es) / 34.93 cm
Height
22.44 inch(es) / 57 cm
Depth
29.13 inch(es) / 73.99 cm
Weight
31 lb(s) / 14.06 kg
