Features
TWO EXTRA-LARGE LIBERTY® COOKING ZONES
Two extra-large Liberty® cooking zones allows more space and flexibility in placing larger cookware.
HeatShift®
Perfect for recipes that require moving from a sauté to a simmer. HeatShift® divides your cooktop into three preset heat zones that allow you to change the power level by simply moving the pot.
MoveMode®
MoveMode® allows you to easily move your pot across the cooktop, and the power level will automatically transfer.
PowerBoost®.
PowerBoost® increases element power by up to 50%, saving time to heat up pots or boil water quicker.
CookSmart® (5-PRESET TEMPERATURE LEVELS)
CookSmart® ensures optimal results with 5 pre-set temperature levels programmed for cooking different types of food.
WI-FI ENABLED FOR CONVENIENT REMOTE MONITORING.
Wi-Fi Enabled cooktop allows for convenient remote monitoring with access to cooktop programs and settings via the Home Connect® app.
Additional Features
INSTANTANEOUS CHANGES IN TEMPERATURE WITH INDUCTION
Superior Responsiveness: Induction technology allows instantaneous temperature changes as the power level is adjusted. Induction automatically recognizes the size, shape and position of your cookware on the cooktop. The cooktop is easy to clean and provides superior responsiveness.
Specifications
General
Series Name
Liberty® Masterpiece® Collection
Color
Grey
Manufacturer Color
Titanium Grey
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• 1 – Power of Back Left Heating Element: 2,200 W / 3,600 W (In Boost)
• 2 – Power of Front Left Heating Element: 2,200 W / 3,600 W (In Boost)
• 3 – Power of Back Right Heating Element: 2,200 W / 3,600 W (In Boost)
• 4 – Power of Front Right Heating Element: 2,200 W / 3,600 W (In Boost)
• Power of Left Area + 1A FlexPlus™ Left Heating Element: 3,300 W / 3,600 W (In Boost)
• Power of Right Area + 3A FlexPlus™ Right Heating Element: 3,300 W / 3,600 W (In Boost)
• 2 – Power of Front Left Heating Element: 2,200 W / 3,600 W (In Boost)
• 3 – Power of Back Right Heating Element: 2,200 W / 3,600 W (In Boost)
• 4 – Power of Front Right Heating Element: 2,200 W / 3,600 W (In Boost)
• Power of Left Area + 1A FlexPlus™ Left Heating Element: 3,300 W / 3,600 W (In Boost)
• Power of Right Area + 3A FlexPlus™ Right Heating Element: 3,300 W / 3,600 W (In Boost)
Burner/Element Size
• Dimension of Back Left Heating Element: 8 1/2" x 7 1/2"
• Dimension of Front Left Heating Element: 8 1/2" x 7 1/2"
• Dimension of Back Right Heating Element: 8 1/2" x 7 1/2"
• Dimension of Front Right Heating Element: 8 1/2" x 7 1/2"
• Dimension of FlexPlus™ Left Heating Element: 3 9/16" x 11 1/4"
• Dimension of FlexPlus™ Right Heating Element: 3 9/16" x 11 1/4"
• Dimension of Front Left Heating Element: 8 1/2" x 7 1/2"
• Dimension of Back Right Heating Element: 8 1/2" x 7 1/2"
• Dimension of Front Right Heating Element: 8 1/2" x 7 1/2"
• Dimension of FlexPlus™ Left Heating Element: 3 9/16" x 11 1/4"
• Dimension of FlexPlus™ Right Heating Element: 3 9/16" x 11 1/4"
Elements
Smoothtop
Features
Technologies
• MoveMode®
• CookSmart®
• PowerBoost®
• PanBoost®
• MoveMode®
• Home Connect® (Wi-Fi Enabled)
• Remote Diagnostics
• CookSmart®
• PowerBoost®
• PanBoost®
• MoveMode®
• Home Connect® (Wi-Fi Enabled)
• Remote Diagnostics
Wi-Fi
Yes
Control Lock
Yes
Digital Display
Yes
Additional Information
• Hotplate Control Settings: 17 Power Levels
• Timer: Kitchen Timer, Stop Watch
• Frying Sensor
• Cooktop Hood Sync
• Timer: Kitchen Timer, Stop Watch
• Frying Sensor
• Cooktop Hood Sync
Electrical Information
Information
• Watts (W): 6,240 / 7,200 W
• Circuit Breaker (A): 30 A
• Volts (V): 208 / 240 V
• Frequency (Hz): 60 Hz
• Conduit: 37" Flexible 3-Wire
• Circuit Breaker (A): 30 A
• Volts (V): 208 / 240 V
• Frequency (Hz): 60 Hz
• Conduit: 37" Flexible 3-Wire
Dimensions
Class Width
30"
Width
31.02 inch(es) / 78.8 cm
Height
3.86 inch(es) / 9.8 cm
Depth
21.26 inch(es) / 54.0 cm
Weight
39 lb(s) / 17.69 kg
Additional Dimensions
• Required Cutout Size (HxWxD) (in): 3 7/8" x 28 3/4" x 19 7/8"
• Minimum Distance From Counter Front (in): 2 1/4"
• Minimum Distance From Rear Wall (in): 2"
• Minimum Distance From Counter Front (in): 2 1/4"
• Minimum Distance From Rear Wall (in): 2"
Warranty
Warranty
Limited Warranty, Entire Appliance, Parts and Labor: 2 Years
