Features
ZERO-CLEARANCE HINGING
Wine Cabinets are revered in the industry, not only because they’re designed to meet the style needs of demanding consumers but also because they satisfy the exacting needs of designers and architects. That’s why True Wine Cabinets feature zero-clearance hinging, which ensures integrated installation in your existing kitchen or in the kitchen you’ve been planning.

Additional Features
PATENTED TRULUMINA® LED LIGHTING
Patented TruLumina® LED lighting gently illuminates your product and allows you to choose from 14 different color options with the push of a button.
Specifications
General
Series Name
300 Series
Capacity
5.8 Cu. Ft.
Bottles
45
Number of Racks
5
Temperature Zones
1
Temperature Settings
40°F (4.4°C) to 65°F (18.3°C)
Installation
Built-In
Type
Cooler
Size
Compact
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Hinge
Right
Features
Technologies
• Patented TruLumina® LED Lighting
• True Precision Control® with Steel Touch Technology
• True Precision Control® with Steel Touch Technology
Digital Temperature Display
Yes
Glass Door
Yes
Interior Light
Yes
Lock
Yes
Additional Information
• Environmentally friendly R600a refrigerant
• Low-E, double pane, UV tinted glass
• 1 floor wine cradle – 5 bottles
• Low-E, double pane, UV tinted glass
• 1 floor wine cradle – 5 bottles
Electrical Information
Information
• Annual Energy Consumption (kwh): 260
• 115 V
• 60 Hz
• 1.9 A
• 115 V
• 60 Hz
• 1.9 A
Certifications and Approvals
Sabbath/Star-K
Yes
Information
UL
Accessories
Optional
• Anti-condensation pads
• Glide-out wine shelf
• Glide-out wine shelf
Dimensions
Width
23.86 inch(es) / 60.6 cm
Height
34.25 inch(es) / 87.0 cm
Depth (Without Handle)
23.9 inch(es) / 60.7 cm
Depth (Including Handle)
25.79 inch(es) / 65.5 cm
Weight
230.01 lb(s) / 104.33 kg
Additional Dimensions
Cutout Dimensions (w x h x d): 24" x 34 1/2" x 24"
Warranty
Warranty
• 3 Year Full (Parts and Labor)
• 6 Year Sealed System (Parts and Labor)
• 7–12 Year (Parts Only – Sealed System on Registered Products)
• 6 Year Sealed System (Parts and Labor)
• 7–12 Year (Parts Only – Sealed System on Registered Products)
