Specifications
General
Type
Beverage Center
Installation
Built-In
Size
Compact
Color
Panel Ready
Manufacturer Color
Panel Ready
Cabinet Color
Black
Temperature Zones
1
Temperature Settings
33°– 41°F (0.5°– 5°C)
Hinge Side
Left
Capacity
Total Capacity
5.0 cu. ft.
Bottles
12
Wine Racks
1
Features
Digital Temperature Display
Yes
Glass Door
Yes
Interior Light
Yes
Additional Information
• Articulating, Soft Close Hinge Allows Fully Integrated, Flexible Installations
• Sleek Black Aluminum Interior
• One Pull-Out PVC Coated Wire Wine Rack and One Floor Wine Cradle for Storage of 12 Total Bottles
• Concealed Digital Temperature Controls Allows for Precise Temperature Management
• Two Adjustable Heavy-Duty PVC Coated Black Wire Shelves Allow for Adjustable Organization Options
• One Pull-Out PVC Coated Wire Wine Rack for Storage of 7 Bottles
• White LED Lighting Illuminates Your Product
• Sleek Black Aluminum Interior
• One Pull-Out PVC Coated Wire Wine Rack and One Floor Wine Cradle for Storage of 12 Total Bottles
• Concealed Digital Temperature Controls Allows for Precise Temperature Management
• Two Adjustable Heavy-Duty PVC Coated Black Wire Shelves Allow for Adjustable Organization Options
• One Pull-Out PVC Coated Wire Wine Rack for Storage of 7 Bottles
• White LED Lighting Illuminates Your Product
Electrical Information
Information
• 115 V
• 60 Hz
• 0.08 A
• 275 Annual Energy Usage
• 60 Hz
• 0.08 A
• 275 Annual Energy Usage
Certifications and Approvals
Information
• ADA
• UL-Rated for Outdoor Use
• Environmentally Friendly R600A Refrigerant
• NSF/ANSI Standard 7 Compliant for Packaged Food Product
• UL-Rated for Outdoor Use
• Environmentally Friendly R600A Refrigerant
• NSF/ANSI Standard 7 Compliant for Packaged Food Product
Dimensions
Class Width
24"
Width
23.9 inch(es) / 60.7 cm
Height
31.89 inch(es) / 81.0 cm
Depth
23.94 inch(es) / 60.8 cm
Weight
145 lb(s) / 65.77 kg
Additional Dimensions
Cutout Dimensions (W x H x D): 24" x 32" x 24"
Warranty
Warranty
• 2 Year Full Parts and Labor
• 5 Year Sealed System Parts and Labor
• 5 Year Sealed System Parts and Labor
