Features
ACT™ CONTROL TECHNOLOGY
Airflow Control Technology (ACT) allows the installer to set the maximum fan CFM to align with local codes and regulations.
Additional Features
ICON TOUCH™ CONTROLS
Seamlessly integrates into the hood’s stainless steel canopy and allows users to easily control the 5-speeds, delay-off function, auto reminders and Airflow Control Technology.
Specifications
General
Series Name
Siena Pro
Blower Included
Yes
Airflow
1200 CFM
Style
Island
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Ceiling Mount
Features
Technologies
• Airflow Control Technology™ (ACT™)
• ICON Touch® Controls
• TruHue™
• ICON Touch® Controls
• TruHue™
Ducting Information
10" Round
Speeds
• Speed Levels: 5*
• Blower CFM (Min. - Max.): 450 - 1,200
• Sones (Min. - Max.): 3.5 - 9
• ACT 590 CFM (Min. - Max.): 350 - 590
• ACT 390 CFM (Min. - Max.): 350 - 390
• *When ACT™ is enabled the maximum speed levels will change. ACT 590 CFM = 3 speeds and ACT 390 CFM = 2 speeds.
• Blower CFM (Min. - Max.): 450 - 1,200
• Sones (Min. - Max.): 3.5 - 9
• ACT 590 CFM (Min. - Max.): 350 - 590
• ACT 390 CFM (Min. - Max.): 350 - 390
• *When ACT™ is enabled the maximum speed levels will change. ACT 590 CFM = 3 speeds and ACT 390 CFM = 2 speeds.
Additional Information
• LumiLight LED with TruHue™, 6W x4
• Dual-Level Lighting
• Quick-Lock Installation System
• Auto Delay-Off
• 2 Hybrid Baffles Filters
• Magnetic Duct Covers
• Dual-Level Lighting
• Quick-Lock Installation System
• Auto Delay-Off
• 2 Hybrid Baffles Filters
• Magnetic Duct Covers
Electrical Information
Information
• 120V
• 60Hz at Max.
• 9A
• 60Hz at Max.
• 9A
Accessories
Optional
• Wireless Remote Control Kit: RC-0002
• Extension Duct Cover: Z1C-02SL
• Make-Up Air Kit: MUA010A
• Extension Duct Cover: Z1C-02SL
• Make-Up Air Kit: MUA010A
Dimensions
Class Width
36"
Width
35.94 inch(es) / 91.28 cm
Height
12 inch(es) / 30.48 cm
Depth
28 inch(es) / 71.12 cm
Additional Dimensions
Mounting Height Range: 24" - 34"
Warranty
Warranty
3 years parts, 1 year labor
