Specifications
General
Series Name
Mercury
Color
Black
Manufacturer Color
Matte Black
Fuel Type
Electric Induction
Type
Rangetop
Cooktop
Burners/Elements
5
Power Output
• Front Left Element: 1.4 kW (Max) 2.2 kW (Boost)
• Rear Left Element: 1.85 kW (Max) 3.0 kW (Boost)
• Center Element: 2.3 kW (Max) 3.7 kW (Boost)
• Front Right Element: 1.85 kW (Max) 3.0 kW (Boost)
• Rear Right Element: 1.85 kW (Max) 3.0 kW (Boost)
• Rear Left Element: 1.85 kW (Max) 3.0 kW (Boost)
• Center Element: 2.3 kW (Max) 3.7 kW (Boost)
• Front Right Element: 1.85 kW (Max) 3.0 kW (Boost)
• Rear Right Element: 1.85 kW (Max) 3.0 kW (Boost)
Elements
Smoothtop
Features
Control Lock
Yes
Additional Information
• Extra-large 35 1/2" W x 21 1/2" D ceramic glass surface with 5 induction burners and facia touch controls efficiently utilizes / transfers / captures 90% of energy generated compared to only 55% with that of a traditional gas burner
• Hob display features: 3700w boost, residual heat indicator, 9 power settings, overheat detection and child safety lock.
• 5 Hi-Fi Style Infinite Controls turn with stereo-like grace
• Hob display features: 3700w boost, residual heat indicator, 9 power settings, overheat detection and child safety lock.
• 5 Hi-Fi Style Infinite Controls turn with stereo-like grace
Electrical Information
Information
• Electric Supply: 240 V 60 Hz
• Electric Rating: 240V (2 Wire + Grd), 60Hz, 11.4 kW
• Branch Circuit Protection: 50 A
• Connection Type: NEMA 14-50 P
• Electric Rating: 240V (2 Wire + Grd), 60Hz, 11.4 kW
• Branch Circuit Protection: 50 A
• Connection Type: NEMA 14-50 P
Dimensions
Class Width
36"
Width
35.43 inch(es) / 90.0 cm
Height
8.15 inch(es) / 20.7 cm
Depth
26.69 inch(es) / 67.8 cm
Weight
88.18 lb(s) / 40 kg
Shipping Dimensions
Weight
100 lb(s) / 45.36 kg
Warranty
Warranty
2 Year Warranty on parts and labor with the exception of cosmetic damage
