Specifications
General
Series Name
Heritage
Refrigerator Type
Bottom Freezer
Installation Type
Freestanding
Door Hinge
Right
Color
White
Manufacturer Color
Black/White
Capacity
Total
18.5 cu. ft.
Refrigerator
12.9 cu. ft.
Freezer
5.6 cu. ft.
Refrigerator Features
Technologies
• Crispers And Bins Made of Clear Durable Lexan™
• SoftSound Quiet Package
• SoftSound Quiet Package
Frost Free
Yes
Interior Light
Yes
Crisper Drawers
Yes
Gallon Door
Yes
Additional Information
• Fully Adjustable Shelving
• Gallon Size Adjustable Door Storage
• Sealed Vegetable Crisper With Adjustable Humidity Control
• Injection Molded Fiber Glass Doors with Enamel Coating
• Adjustable Rollers Provide Easy Movement For Cleaning
• Sculptured Door Handles
• Coil Free Back, Clean-free Condenser
• Nickel Standard Door Handles
• Gallon Size Adjustable Door Storage
• Sealed Vegetable Crisper With Adjustable Humidity Control
• Injection Molded Fiber Glass Doors with Enamel Coating
• Adjustable Rollers Provide Easy Movement For Cleaning
• Sculptured Door Handles
• Coil Free Back, Clean-free Condenser
• Nickel Standard Door Handles
Freezer Features
Additional Freezer Information
• Slide Out Upper Freezer Basket
• Separate Fridge / Freezer Controls
• Separate Fridge / Freezer Controls
Electrical Information
Information
Energuide rating (KwH/year): 448
Certifications and Approvals
Energy Star Certified
Yes
Accessories
Optional
• Factory Installed Ice Maker
• Left Hand Hinge
• Antique Brass or Antique Copper Door Handles
• Nickel, Antique Brass or Antique Copper Door Frames (Required on this Model)
• Left Hand Hinge
• Antique Brass or Antique Copper Door Handles
• Nickel, Antique Brass or Antique Copper Door Frames (Required on this Model)
Dimensions
Class Width
29" to 31.9"
Class Height
65" - 70"
Width
30 inch(es) / 76.2 cm
Height (With Hinge)
67.25 inch(es) / 170.82 cm
Depth (Without Handles)
33.75 inch(es) / 85.73 cm
Additional Dimensions
• Cutout Dimensions: Width 30", Height 67", Minimum Depth 24", Ideal Depth 28"
• Height To Top Of Door: 67-1/4"
• Height To Top Of Case*: 65-3/4"
• *case Cap Can Be Removed On Models 1958 / 1959 – Reduces Case Height By 3-5/16", To 68-5/8". Height To Top Of Hinge With Cap Removed Is 69-3/8". Features & Specifications Subject To Change. (If Necessary, Allow Clearance Over Fridge Doors For Overhead Cabinet Door Swings.)
• Depth Not Including Door: 28-1/4"
• Depth Including Door And Handles: 33-3/4"
• Depth With Door(S) Open 90 Degrees: 59-1/2"
• Depth With Freezer Drawer Open: 52-1/2"
• Width Of Case: 29-1/4"
• Width With Door(S): 30"
• Width With Door(S) Open 90 Degrees (Not Inc. Handle): 32-1/4"
• Side Clearance From Wall For Doors To Open 90 Degrees: 2-1/2"
• Height To Top Of Door: 67-1/4"
• Height To Top Of Case*: 65-3/4"
• *case Cap Can Be Removed On Models 1958 / 1959 – Reduces Case Height By 3-5/16", To 68-5/8". Height To Top Of Hinge With Cap Removed Is 69-3/8". Features & Specifications Subject To Change. (If Necessary, Allow Clearance Over Fridge Doors For Overhead Cabinet Door Swings.)
• Depth Not Including Door: 28-1/4"
• Depth Including Door And Handles: 33-3/4"
• Depth With Door(S) Open 90 Degrees: 59-1/2"
• Depth With Freezer Drawer Open: 52-1/2"
• Width Of Case: 29-1/4"
• Width With Door(S): 30"
• Width With Door(S) Open 90 Degrees (Not Inc. Handle): 32-1/4"
• Side Clearance From Wall For Doors To Open 90 Degrees: 2-1/2"
Shipping Dimensions
Weight
370 lb(s) / 167.83 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
