Specifications
General
Series Name
Northstar
Fuel Type
Dual Fuel - Natural Gas
Installation Type
Freestanding
Color
Blue
Manufacturer Color
Tropical Blue
Cooktop
Burners/Elements
6
Burners/Elements Output
• 3x Rear Burners: 8,000 BTU
• 1x Front Left Burner: 15,000 BTU
• 1x Front Right Burner: 15,000 BTU
• 1x Front Center Burner: 12,000 BTU
• (Ratings are for Natural Gas; Liquid Propane is approximately 10% lower)
• 1x Front Left Burner: 15,000 BTU
• 1x Front Right Burner: 15,000 BTU
• 1x Front Center Burner: 12,000 BTU
• (Ratings are for Natural Gas; Liquid Propane is approximately 10% lower)
Burners
Sealed
Oven
Capacity (cu. ft.)
5.0
Number of Ovens
Single
Features
Convection
Yes
Delay Bake/Start
Yes
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
Yes
Wi-Fi
No
Additional Information
• Gas Sealed Burners with Cast Grates
• Delayed Start Baking / Cleaning
• Variable Temperature Broil
• Door-Activated Light with Override: Hologen
• Standard True Convection
• Electronic Spark with Re-Ignition
• Delayed Start Baking / Cleaning
• Variable Temperature Broil
• Door-Activated Light with Override: Hologen
• Standard True Convection
• Electronic Spark with Re-Ignition
Drawer Features
Storage
Yes
Electrical Information
Information
220V
Dimensions
Class Width
36"
Width
36 inch(es) / 91.44 cm
Height
49 inch(es) / 124.46 cm
Depth (Including Handles)
28.5 inch(es) / 72.39 cm
Additional Dimensions
• Height to Cooking Surface: 37-1/4"
• Depth (plus 2" handles): 28-1/2"
• Interior Oven: Width 31", Height 15-1/2", Depth ( Convection) 18"
• Drawer Dimensions: 26-3/4" W x 22-1/2" D x 5-3/8" H
• Depth (plus 2" handles): 28-1/2"
• Interior Oven: Width 31", Height 15-1/2", Depth ( Convection) 18"
• Drawer Dimensions: 26-3/4" W x 22-1/2" D x 5-3/8" H
Shipping Dimensions
Weight
375.01 lb(s) / 170.1 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
