Features
DEFROST
The circulation of air at room temperature enables quicker thawing of frozen food, (without the use of any heat). Ideal for use prior to
cooking of readymade dishes, or cream filled products etc.
Additional Features
EUROPEAN CONVECTION
Hot air fan cooking that provides quick, multi layered cooking with excellent browning results. Due to the effective circulation of hot air, there is no flavour transfer between foods. Delicate and strongly fragranced foods can be cooked at the same time.
PIZZA FUNCTION
The simultaneous operation of these three elements ensures an optimum cooking facility, ideal not only for pizza but also for cookies, quiches and flans.
CONVECTION BAKE
The elements combined with the fan aim to provide more uniform heat, a similar method to conventional cooking, so pre-heat is required. Most suitable for items requiring slow cooking methods.
CONVECTION BROIL
The fan reduces the fierce heat from the broiler, providing an excellent method of grilling various foods, chops, steaks, sausages etc. giving even browning and heat distribution, without drying out the food. The top two levels recommended for use, and the lower part of the oven can be used to keep items warm at the same time, an excellent facility when cooking a grilled breakfast.
Specifications
General
Series Name
Portofino Aesthetic
Fuel Type
Dual Fuel - Natural Gas
Installation Type
Freestanding
Color
Red
Manufacturer Color
Red
Cooktop
Burners/Elements
4
Burners/Elements Output
• Center-Rear Burner: 4,500 BTU
• Center-Front Burner: 8,000 BTU
• Right Super Burner: 20,000 BTU
• Left Double-Inset Super Burner: 20,000 BTU
• Center-Front Burner: 8,000 BTU
• Right Super Burner: 20,000 BTU
• Left Double-Inset Super Burner: 20,000 BTU
Burners
Sealed
Oven
Capacity (cu. ft.)
3.6 cu.ft.
Number of Ovens
Single
Features
Technologies
True European Convection Technolgy
Convection
Yes
Digital Temperature Display
Yes
Additional Information
• Full-Width Continuous Grates
• 10 Cooking Modes Including Pizza Function
• Programmable Timer with Touch Display
• Adjustable Thermostat 120° - 500°F
• Air-cooled Triple-Glazed Removable Door
• 4 Shelf Positions
• 2 X Halogen Oven Lights
• Bake Element: 1.7 Kw
• Broil Element: 2.9 Kw
• Convection Element: 2.7 Kw
• Heavy-duty Cast Iron Grates
• Automatic Electric Ignition
• Gas Safety Valves
• Air-Cooled Door to Prevent Overheating
• 10 Cooking Modes Including Pizza Function
• Programmable Timer with Touch Display
• Adjustable Thermostat 120° - 500°F
• Air-cooled Triple-Glazed Removable Door
• 4 Shelf Positions
• 2 X Halogen Oven Lights
• Bake Element: 1.7 Kw
• Broil Element: 2.9 Kw
• Convection Element: 2.7 Kw
• Heavy-duty Cast Iron Grates
• Automatic Electric Ignition
• Gas Safety Valves
• Air-Cooled Door to Prevent Overheating
Drawer Features
Storage
Yes
Electrical Information
Information
• 240 V /120 V
• 60 Hz
• 60 Hz
Accessories
Included
• LP Gas Conversion Kit
• 1 Wok Ring
• 1 Deep Oven Tray
• 1 Partial-Extraction Telescopic Guide
• 2 Chrome Shelves
• 1 Wok Ring
• 1 Deep Oven Tray
• 1 Partial-Extraction Telescopic Guide
• 2 Chrome Shelves
Optional
• BGCPF30 - Grill Plate
• GT91P - 1-Level Telescopic Shelf – Partial Extraction
• PPR9 - Pizza Stone
• TPKCPF30 - Teppanyaki Grill Plate
• GT91P - 1-Level Telescopic Shelf – Partial Extraction
• PPR9 - Pizza Stone
• TPKCPF30 - Teppanyaki Grill Plate
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
37.31 inch(es) / 94.77 cm
Depth (Without Handles)
25 inch(es) / 63.5 cm
Warranty
Warranty
Limited 1 Year Parts and Labor
UPC
UPC#
8017709256692
